Danfoss VLT AHF 005 Service Guide

Block Diagram Name
Spare Part Number
Spare part name Comments 525–690 VAC (T7)
E1h/E3h E2h/E4h FC 102 N450 N500 N560 N630 N710 N800 FC 103 N450 N500 N560 N630 N710 N800 FC 202 N450 N500 N560 N630 N710 N800 FC 302 N355 N400 N500 N560 N630 N710
176F6664 Busbar, DC neg, DC link ind to CAPB, E1,E3 Connects DC coil - input to cap bank, right side of drive 1 1 1 1 – – 176F6665 Busbar, DC neg, DC link ind to CAPB, E2,E4 Connects DC coil - input to cap bank, right side of drive – – – – 1 1 176F6666 Busbar, DC pos, DC link ind to CAPB, E1,E2 Connects DC coil + input to cap bank, left side of drive 1 1 1 1 – – 176F6667 Busbar, DC pos, DC link ind to CAPB, E2,E4 Connects DC coil + input to cap bank, left side of drive – – – – 1 1 176F6684 Busbar insulator set, T7 E1 P4001 Set of 3 cap bank busbars with Mylar insulators 1 1 1 1 – –
176F6685 Busbar insulator set, T7 E2 P4001 Set of 3 cap bank busbars with Mylar insulators – – – – 1 1
176F6673 Busbar, IGBT AC OUTPUT, E1,E3 IGBT AC output, goes over the IGBT, 1 per kit 3 3 3 3 – –
176F6674 Busbar, IGBT AC OUTPUT, E2,E4 IGBT AC output, goes over the IGBT, 1 per kit – – – – 3 3
176F6659 Busbar, current sensor, E1hE3h Busbars through sensors, 1 per kit 1 1 1 1 – – 176F6660 Busbar, current sensor, E2hE4h Busbars through sensors, 1 per kit – – – – 1 1 176F3839 Busbar, motor, U, E1hE3h Busbar, connects C/T bar to right angle bar 1 1 1 1 – – 176F3840 Busbar, motor, V, E1hE3h Busbar, connects C/T bar to right angle bar 1 1 1 1 – –
176F3841 Busbar, motor, W, E1hE3h Busbar, connects C/T bar to right angle bar 1 1 1 1 – – 176F3844 Busbar, motor, U, E2hE4h Busbar, connects C/T bar to right angle bar – – – – 1 1 176F3846 Busbar, motor, V, E2hE4h Busbar, connects C/T bar to right angle bar 176F3845 Busbar, motor, W, E2hE4h Busbar, connects C/T bar to right angle bar TB1 176F6689 Busbar terminal, E1h–E4h Mains terminal busbars (L1,L2,L3) 3 3 3 3 3 3 TB2 176F6689 Busbar terminal, E1h–E4h Motor terminal busbars (U,V,W) 3 3 3 3 3 3 Other Parts
176F3353 Door fan lter Dh frame package of 10 IP21/IP54 door lter 2 per drive, 10 per kit 2 2 2 2 2 2 176F3375 Door vent kit IP21/IP54 Dh frame Door vent kit, no fan 2 2 2 2 2 2 TB1 176F6686 Terminal suppt, main, motor, E1h–E4h Mains terminal insulation block 3 3 3 3 3 3
TB2 176F6686 Terminal suppt, main, motor, E1h–E4h Motor terminal insulation block 3 3 3 3 3 3 176F6668 Cover, E3h front, top panel Front cover IP20 E3h IP20 IP20 IP20 IP20 – –
176F6669 Cover, E3h front, lower panel Front cover IP20 E3h IP20 IP20 IP20 IP20 – –
176F6670 Cover, E4h front, top panel Front cover IP20 E4h – – – – IP20 IP20
176F6671 Cover, E4h front, lower panel Front cover IP20 E4h – – – – IP20 IP20 176F6678 Cover, mains shield covers, E1 Mains shield E1 1 1 1 1 – –
176F6679 Cover, mains shield covers, E2 Mains shield E2 – – – – 1 1
Spare Parts
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
354 Danfoss A/S © 02/2019 All rights reserved. MG94A502
