22-83 Speed at No-Flow [RPM]
Range: Function:
Size
related*
[ 0 -
par.
22-85
RPM]
Resolution 1 RPM.
The speed of the motor at which flow Is
zero and minimum pressure H
MIN
is achieved
should be entered here in RPM. Alterna-
tively, the speed in Hz can be entered in
parameter 22-84 Speed at No-Flow [Hz]. If it
has been decided to use RPM in 0-02 Motor
Speed Unit then parameter 22-85 Speed at
Design Point [RPM] should also be used.
Closing the valves and reducing the speed
until minimum pressure H
MIN
is achieved
determines this value.
22-84 Speed at No-Flow [Hz]
Range: Function:
Size
related*
[ 0 -
par.
22-86
Hz]
Resolution 0.033 Hz.
The speed of the motor at which flow has
effectively stopped and minimum pressure
H
MIN
is achieved should be entered here in
Hz. Alternatively, the speed in RPM can be
entered in parameter 22-83 Speed at No-Flow
[RPM]. If it has been decided to use Hz in
0-02 Motor Speed Unit then
parameter 22-86 Speed at Design Point [Hz]
should also be used. Closing the valves and
reducing the speed until minimum pressure
H
MIN
is achieved determines this value.
22-85 Speed at Design Point [RPM]
Range: Function:
Size
related*
[ 0 -
60000
RPM]
Resolution 1 RPM.
Only visible when parameter 22-82 Work
Point Calculation is set to Disable. The
speed of the motor at which the System
Design Working Point is achieved should
be entered here in RPM. Alternatively, the
speed in Hz can be entered in
parameter 22-86 Speed at Design Point [Hz].
If it has been decided to use RPM in
0-02 Motor Speed Unit then
parameter 22-83 Speed at No-Flow [RPM]
should also be used.
22-86 Speed at Design Point [Hz]
Range: Function:
Size
related*
[ 0.0 -
par.
4-19
Hz]
Resolution 0.033 Hz.
Only visible when parameter 22-82 Work
Point Calculation is set to Disable. The speed
of the motor at which the System Design
Working Point is achieved should be
entered here in Hz. Alternatively, the speed
in RPM can be entered in
parameter 22-85 Speed at Design Point [RPM].
22-86 Speed at Design Point [Hz]
Range: Function:
If it has been decided to use Hz in
0-02 Motor Speed Unit, then
parameter 22-83 Speed at No-Flow [RPM]
should also be used.
22-87 Pressure at No-Flow Speed
Range: Function:
0 * [ 0 - par. 22-88 ] Enter the pressure H
MIN
corresponding to
Speed at No Flow in Reference/Feedback
Units.
Also see parameter 22-82 Work Point Calculation point D.
22-88 Pressure at Rated Speed
Range: Function:
999999.999 * [ par. 22-87 -
999999.999 ]
Enter the value corresponding
to the Pressure at Rated Speed,
in Reference/Feedback Units.
This value can be defined using
the pump datasheet.
Also see parameter 22-82 Work Point Calculation point C.
22-90 Flow at Rated Speed
Range: Function:
0 * [0 - 999999.999 ] Enter the value corresponding to Flow at
Rated Speed. This value can be defined
using the pump datasheet.
5.2.10 23-0* Timed Actions
Use Timed Actions for actions needing to be performed on
a daily or weekly basis, e.g. different references for working
hours/non-working hours. Up to 10 Timed Actions can be
programmed in the frequency converter. The Timed Action
number is selected from the list when entering parameter
group 23-0* from the LCP. Parameter 23-00 ON Time –
parameter 23-04 Occurrence then refer to the selected
Timed Action number. Each Timed Action is divided into
an ON time and an OFF time, in which 2 different actions
may be performed.
The clock control (parameter group 0-7* Clock Settings) of
Timed Actions can be overridden from Timed Actions Auto
(Clock Controlled) to Timed Actions Disabled, Constant OFF
Actions or Constant ON Actions either in 23-08 Timed
Actions Mode or with commands applied to the digital
inputs ([68] Timed Actions Disabled, [69] Constant OFF
Actions or [70] Constant ON Actions, in parameter group
5-1* Digital Inputs.
How to programme the freque...
VLT AQUA Drive FC 202 Operation Instructions
108 MG20P402 - Rev. 2013-12-16
