Danfoss VLT AutomationDrive FC 300 Instruction Manual

Control card, USB serial communication:
USB standard 1.1 (Full speed)
USB plug USB type B “device” plug
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB ground connection is
not galvanically isolated from protection ground. Use only an isolated laptop as PC connection to the USB connector on
the adjustable frequency drive.
Relay outputs:
Programmable relay outputs FC 301all kW: 1 / FC 302 all kW: 2
Relay 01 Terminal number 1-3 (break), 1-2 (make)
Max. terminal load (AC-1)
1)
on 1-3 (NC), 1-2 (NO) (Resistive load) 240 V AC, 2 A
Max. terminal load (AC-15)
1)
(Inductive load @ cos 0.4) 240 V AC, 0.2 A
Max. terminal load (DC-1)
1)
on 1-2 (NO), 1-3 (NC) (Resistive load) 60 V DC, 1A
Max. terminal load (DC-13)
1)
(Inductive load) 24 V DC, 0.1A
Relay 02 (FC 302 only) Terminal number 4-6 (break), 4-5 (make)
Max. terminal load (AC-1)
1)
on 4-5 (NO) (Resistive load)
2)3)
Overvoltage cat. II 400 V AC, 2 A
Max. terminal load (AC-15)
1)
on 4-5 (NO) (Inductive load @ cos 0.4) 240 V AC, 0.2 A
Max. terminal load (DC-1)
1)
on 4-5 (NO) (Resistive load) 80 V DC, 2 A
Max. terminal load (DC-13)
1)
on 4-5 (NO) (Inductive load) 24 V DC, 0.1A
Max. terminal load (AC-1)
1)
on 4-6 (NC) (Resistive load) 240 V AC, 2 A
Max. terminal load (AC-15)
1)
on 4-6 (NC) (Inductive load @ cos 0.4) 240 V AC, 0.2 A
Max. terminal load (DC-1)
1)
on 4-6 (NC) (Resistive load) 50 V DC, 2 A
Max. terminal load (DC-13)
1)
on 4-6 (NC) (Inductive load) 24 V DC, 0.1 A
Min. terminal load on 1-3 (NC), 1-2 (NO), 4-6 (NC), 4-5 (NO) 24 V DC 10 mA, 24 V AC 20 mA
Environment according to EN 60664-1 overvoltage category III/pollution degree 2
1) IEC 60947 part 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
2) Overvoltage Category II
3) UL applications 300 V AC 2A
Cable lengths and cross-sections for control cables*:
Max. motor cable length, shielded FC 301: 164 ft [50 m] / FC 301 (A1): 82 ft [25 m]/ FC 302: 492 ft [150 m]
Max. motor cable length, non-shielded FC 301: 246 ft [75 m] / FC 301 (A1): 164 ft [50 m]/ FC 302: 984 ft [300 m]
Maximum cross-section to control terminals, flexible/rigid wire without cable end sleeves 0.0023 in
2
[1.5 mm
2
]/16 AWG
Maximum cross-section to control terminals, flexible wire with cable end sleeves 0.0016 in
2
[1 mm
2
]/18 AWG
Maximum cross-section to control terminals, flexible wire with cable end sleeves with collar 0.0008 in
2
[0.5 mm
2
]/20 AWG
Minimum cross-section to control terminals 0.0039 in
2
[0.25 mm
2
]/24 AWG
* Power cables, see tables in section “Electrical Data” of the Design Guide
For more information, see section Electrical Data in the VLT AutomationDrive Design Guide, MG.33.BX.YY.
Control card performance:
Scan interval FC 301: 5 ms / FC 302: 1 ms
Control characteristics:
Resolution of output frequency at 0–1000 Hz +/- 0.003 Hz
Repeat accuracy of Precise start/stop (terminals 18, 19) ≤± 0.1 msec
System response time (terminals 18, 19, 27, 29, 32, 33) ≤ 2 ms
Speed control range (open-loop) 1:100 of synchronous speed
Speed control range (closed-loop) 1:1000 of synchronous speed
Speed accuracy (open-loop) 30–4000 rpm: error ±8 rpm
Speed accuracy (closed-loop), depending on resolution of feedback device 0–6000 rpm: error ±0.15 rpm
All control characteristics are based on a 4-pole asynchronous motor
5 General Specifications
VLT
®
AutomationDrive FC 300 Instruction
Manual
5-4 MG.33.AG.22 - VLT
®
is a registered Danfoss trademark
5
