15-43 Software Version
Range: Function:
0 N/A* [0 - 0 N/A] View the combined SW version (or ‘package version’) consisting of power SW and control SW.
4.4 Parameter Lists
Changes during operation
”TRUE” means that the parameter can be changed while the adjustable frequency drive is in operation, and “FALSE” means that it must be stopped before
a change can be made.
4-Set-up
'All set-up': the parameters can be set individually in each of the four set-ups, i.e., one single parameter can have four different data values.
’1 set-up’: the data value will be the same in all set-ups.
Conversion index
This number refers to a conversion figure used when writing or reading to and from the adjustable frequency drive.
Conv. index 100 67 6 5 4 3 2 1 0 -1 -2 -3 -4 -5 -6
Conv. factor 1 1/60 1000000 100000 10000 1000 100 10 1 0.1 0.01 0.001 0.0001 0.00001 0.000001
Data type Description Type
2Integer 8 Int8
3 Integer 16 Int16
4Integer 32 Int32
5 Unsigned 8 Uint8
6 Unsigned 16 Uint16
7 Unsigned 32 Uint32
9 Visible String VisStr
33 Normalized value 2 bytes N2
35 Bit sequence of 16 boolean variables V2
54 Time difference w/o date TimD
See the adjustable frequency drive
Design Guide
for further information about data types 33, 35 and 54.
