Danfoss VLT AutomationDrive FC 300 Instruction Manual

Frame
Tightening torque for covers (Nm)
IP20 IP21 IP55 IP66
A1 * - - -
A2 * * - -
A3 * * - -
A4/A5 - - 2 2
B1 - * 2.2 2.2
B2 - * 2.2 2.2
B3 * - - -
B4 2 - - -
C1 - * 2.2 2.2
C2 - * 2.2 2.2
C3 2 - - -
C4 2 - - -
* = No screws to tighten
- = Does not exist
3.2.2 Panel Through Mounting
A Panel Through Mount Kit is available for adjustable frequency drive series VLT HVAC FC 102, VLT Aqua Drive and VLT AutomationDrive.
In order to increase heatsink cooling and reduce panel depth, the adjustable frequency drive may be mounted in a through panel. Furthermore, the built-
in fan can then be removed.
The kit is available for enclosures A5 through C2.
NOTE!
This kit cannot be used with cast front covers. IP21 plastic cover must be used instead.
Information on ordering numbers is found in the Design Guide , section Ordering Numbers.
More detailed information is available in the Panel Through Mount Kit instruction, MI.33.HX.YY, where yy=language code.
3 How to Install
VLT
®
AutomationDrive FC 300 Instruction
Manual
3-6 MG.33.AG.22 - VLT
®
is a registered Danfoss trademark
3
