Danfoss VLT AutomationDrive FC 300 Instruction Manual

Adjustable Frequency Drive
Type
Max. fuse size
1)
Min. rated voltage Type
K25-K75 10A 200–240 V type gG
1K1-2K2 20A 200–240 V type gG
3K0-3K7 32A 200–240 V type gG
5K5-7K5 63A 200–240 V type gG
11K 80A 200–240 V type gG
15K-18K5 125A 200–240 V type gG
22K 160A 200–240 V type aR
30K 200A 200–240 V type aR
37K 250A 200–240 V type aR
1) Max. fuses - refer to national/international regulations to select an appropriate fuse size.
Adjustable Frequency Drive
Type
Max. fuse size
1)
Min. rated voltage Type
K37-1K5 10A 380–500 V type gG
2K2-4K0 20A 380–500 V type gG
5K5-7K5 32A 380–500 V type gG
11K-18K 63A 380–500 V type gG
22K 80A 380–500 V type gG
30K 100A 380–500 V type gG
37K 125A 380–500 V type gG
45K 160A 380–500 V type aR
55K-75K 250A 380–500 V type aR
UL Compliance
200–240 V
Adjustable Fre-
quency Drive
Type
Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
kW Type RK1 Type J Type T Type CC Type CC Type CC
K25-K37 KTN-R05 JKS-05 JJN-06 FNQ-R-5 KTK-R-5 LP-CC-5
K55-1K1 KTN-R10 JKS-10 JJN-10 FNQ-R-10 KTK-R-10 LP-CC-10
1K5 KTN-R15 JKS-15 JJN-15 FNQ-R-15 KTK-R-15 LP-CC-15
2K2 KTN-R20 JKS-20 JJN-20 FNQ-R-20 KTK-R-20 LP-CC-20
3K0 KTN-R25 JKS-25 JJN-25 FNQ-R-25 KTK-R-25 LP-CC-25
3K7 KTN-R30 JKS-30 JJN-30 FNQ-R-30 KTK-R-30 LP-CC-30
5K5 KTN-R50 KS-50 JJN-50 - - -
7K5 KTN-R60 JKS-60 JJN-60 - - -
11K KTN-R80 JKS-80 JJN-80 - - -
15K-18K5 KTN-R125 JKS-150 JJN-125 - - -
Adjustable Frequency
Drive Type
SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
kW Type RK1 Type RK1 Type CC Type RK1
K25-K37 5017906-005 KLN-R05 ATM-R05 A2K-05R
K55-1K1 5017906-010 KLN-R10 ATM-R10 A2K-10R
1K5 5017906-016 KLN-R15 ATM-R15 A2K-15R
2K2 5017906-020 KLN-R20 ATM-R20 A2K-20R
3K0 5017906-025 KLN-R25 ATM-R25 A2K-25R
3K7 5012406-032 KLN-R30 ATM-R30 A2K-30R
5K5 5014006-050 KLN-R50 - A2K-50R
7K5 5014006-063 KLN-R60 - A2K-60R
11K 5014006-080 KLN-R80 - A2K-80R
15K-18K5 2028220-125 KLN-R125 - A2K-125R
Adjustable Frequency
Drive Type
Bussmann SIBA Littel fuse
Ferraz-
Shawmut
kW Type JFHR2 Type RK1 JFHR2 JFHR2
22K FWX-150 2028220-150 L25S-150 A25X-150
30K FWX-200 2028220-200 L25S-200 A25X-200
37K FWX-250 2028220-250 L25S-250 A25X-250
KTS fuses from Bussmann may substitute for KTN for 240 V adjustable frequency drives.
FWH fuses from Bussmann may substitute for FWX for 240 V adjustable frequency drives.
VLT
®
AutomationDrive FC 300 Instruction
Manual
3 How to Install
MG.33.AG.22 - VLT
®
is a registered Danfoss trademark 3-17
3
