Adjustable Frequency
Drive Type
SIBA Littel fuse
Ferraz-
Shawmut
kW Type RK1 Type RK1 Type RK1
K75-1K5 5017906-005 KLSR005 A6K-5R
2K2-4K0 5017906-010 KLSR010 A6K-10R
5K5-7K5 5017906-020 KLSR020 A6K-20R
Adjustable Frequency
Drive Type
Bussmann SIBA
Ferraz-
Shawmut
kW JFHR2 Type RK1 Type RK1
P37K 170M3013 2061032.125 6.6URD30D08A0125
P45K 170M3014 2061032.160 6.6URD30D08A0160
P55K 170M3015 2061032.200 6.6URD30D08A0200
P75K 170M3015 2061032.200 6.6URD30D08A0200
170M fuses shown from Bussmann use the -/80 visual indicator. –TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted.
170M fuses from Bussmann when provided in the 525–600/690 V FC 302 P37K-P75K, FC 102 P75K, or P45K-P90K drives are 170M3015.
170M fuses from Bussmann when provided in the 525–600/690 V FC 302 P90K-P132, FC 102 P90K-P132, or P110-P160 drives are 170M3018.
170M fuses from Bussmann when provided in the 525–600/690 V FC 302 P160-P315, FC 102 P160-P315, or P200-P400 drives are 170M5011.
VLT
®
AutomationDrive FC 300 Instruction
Manual
3 How to Install
MG.33.AG.22 - VLT
®
is a registered Danfoss trademark 3-19
