[47] Bus ctrl, 0 if timeout Controls output via bus. The state of the output is set in par. 5-90
Digital & Relay Bus Control
. In
the event of a bus timeout, the output state is set low (Off).
[51] MCO controlled Active when a MCO 302 or MCO 305 is connected. The output is controlled from option.
[60] Comparator 0 See par. group 13-1* (Smart Logic Control). If Comparator 0 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[61] Comparator 1 See par. group 13-1* (Smart Logic Control). If Comparator 1 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[62] Comparator 2 See par. group 13-1* (Smart Logic Control). If Comparator 2 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[63] Comparator 3 See par. group 13-1* (Smart Logic Control). If Comparator 3 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[64] Comparator 4 See par. group 13-1* (Smart Logic Control). If Comparator 4 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[65] Comparator 5 See par. group 13-1* (Smart Logic Control). If Comparator 5 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[70] Logic rule 0 See par. group 13-4* (Smart Logic Control). If Logic Rule 0 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[71] Logic rule 1 See par. group 13-4* (Smart Logic Control). If Logic Rule 1 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[72] Logic rule 2 See par. group 13-4* (Smart Logic Control). If Logic Rule 2 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[73] Logic rule 3 See par. group 13-4* (Smart Logic Control). If Logic Rule 3 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[74] Logic rule 4 See par. group 13-4* (Smart Logic Control). If Logic Rule 4 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[75] Logic rule 5 See par. group 13-4* (Smart Logic Control). If Logic Rule 5 in SLC is TRUE, the output will go high.
Otherwise, it will be low.
[80] SL digital output A See par. 13-52 ‘Smart Logic Control Action’. Output A is low on Smart Logic Action [32]. Output A
is high on Smart Logic Action [38].
[81] SL digital output B See par. 13-52 ‘Smart Logic Control Action’. Output B is low on Smart Logic Action [33]. Output B
is high on Smart Logic Action [39].
[82] SL digital output C See par. 13-52 ‘Smart Logic Control Action’. Output C is low on Smart Logic Action [34]. Output C
is high on Smart Logic Action [40].
[83] SL digital output D See par. 13-52 ‘Smart Logic Control Action’. Output D is low on Smart Logic Action [35]. Output D
is high on Smart Logic Action [41]
[84] SL digital output E See par. 13-52 ‘Smart Logic Control Action’. Output E is low on Smart Logic Action [36]. Output E
is high on Smart Logic Action [42].
[85] SL digital output F See par. 13-52 ‘Smart Logic Control Action’. Output F is low on Smart Logic Action [37]. Output F
is high on Smart Logic Action [43].
[120] Local ref active Output is high when par. 3-13 Reference Site = [2] Local or when par. 3-13 Reference Site = [0]
Linked to hand auto at the same time as the LCP is in hand on mode.
