FC 300 Design Guide
How to Program
Function:
Address selection for the FC (standard) port.
Valid range: 1 - 126.
8-32 FC Port Baud Rate
Option:
2400 Baud [0]
4800 Baud [1]
*
9600 Baud [2]
19200 Baud [3]
38400 Baud [4]
115200 Baud [7]
Function:
Baud rate selection for the FC (standard) por t.
8-35 Minimum Response Delay
Range:
1-500ms
*
10ms
Function:
Specifies a minim u m delay time between receiving
a request and transmitting a response. This is used
for overcoming modem turna round delays.
8-36 Max Response Delay
Range:
1 - 10000 ms
*
5000ms
Function:
Specifies a maximum allowed delay time between
transmitting a request and expecting a response.
Exceeding this delay causes control w ord timeout.
8-37 Max Inter -Char Delay
Range:
0-30ms
*
25ms
Function:
Maximum waiting ti me between two received b ytes.
It ensures timeout, if transmission is interrupted.
Note: This is only enforced when the FC MC
protocol is selected in par. 8-30.
" 8-5* Digital/Bus
8-50 Coasting Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Allows a choice between controlling the
coasting function via the terminals (digital
input) and/or via the bus.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-51 Quick Stop Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Allows a choice between controlling the
Quick stop function via the term inal s (dig ital
input) and/or via the bus.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-52 DC Brake Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Allows a choice between controlling the DC brake
via the terminals (digital input) and/or v ia the bus.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-53 Start Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
*
default setting ()display text []value for use in communication via serial communication port
184
MG.33.B
3.22 - VLT is a registered Danfoss trademark
