How to Program
Bit 12, Relay 02:
Bit 12 = "0": Relay 2 is not activated. Bit 12 = "1": Relay 02 is activated provide d
that Control word bit 12 is chosen in par. 5-40.
B
it 13/14, Selection of set-up:
Usebits13and14tochoosefromthefour
menu set-ups according to the shown table. The
function is only possible w hen Multi Set-Ups is
selected in par. 0-10 Active Set-Up.
NOTE
Make a se lection in par. 8-55
Set-up sele ct to define how Bit
13/14 gates w ith the corresponding
function on the digital inputs.
Set-up B it 14 Bit 13
100
201
310
411
Bit 15 Reverse:
Bit 1 5 = "0": No reverse Bit 15 = "1": Reverse. In the default setting, reverse is set to digital in par. 8-54
Reversing select. Bit 15 causes reverse only when Ser. communication, Logic or or Logic and is selected.
*
default setting ()display text []value for use in communication via serial c ommunication port
