FC 300 Design Guide
How to Program
Bits 13/14, Set-up selection
Choose between the four parameter set-ups via
bits 13 and 14 according to the shown table:
The function is only possible if you choose Multi
Set-up in par. 0-10. The selection in par. 8-55
Set-up Select determines how bits 13 and 14
link with the corresp onding function of the digital
inputs. When the motor is running, you can
only chang e the set-up if it is linked.
Set-up B it 13 Bit 14
100
210
301
411
Bit 15, No func tion/Reverse
Reverse of the motor rotational direction. Bit 15 = " 0": No reverse. Bit 15 = "1": Reverse. The reverse in
the default setting in par. 8-54 Reversing Select is "Logic OR". Bit 15 causes a reverse only when "Bus",
"Logic OR", or "Logic AND" is se lect ed ("Logic AN D" only in conne ction with term inal 9, however).
NOTE
Unless otherwise indicated, the control word bit links with the corresponding
digital input function as a logic "OR".
*
default setting ()display text []value for use in communication via serial c ommunication port
250
MG.33.B
3.22 - VLT is a registered Danfoss trademark
