Danfoss VLT AutomationDrive FC 302 Design Guide

FC 300 Design Guide
How to Select Your VLT
1. FortypeoffuseseesectionFuses.
2. American Wire Gauge.
3. Measured using 16 ft (5 m) shielded motor cables at rated l oad and rated frequency.
" Mains Supply 3 x 380 - 500 VAC
FC 301/FC 302
Typica l Shaft Output [HP, kW ]
0,25 0.37 0.55 0.75 1.1 1.5 2.2 3 3.7 4 5.5 7.5
Output current
Continuous
(3 x 380-440 V) [A]
- 1.3 1.8 2.4 3 4.1 5 .6 7.2 - 10 13 16
Intermittent
(3 x 380-440 V) [A]
- 2.1 2.9 3.8 4.8 6.6 9.0 11.5 - 16 20.8 25.6
Continuous
(3 x 440-500 V) [A]
- 1.2 1.6 2.1 2.7 3.4 4.8 6.3 - 8.2 11 14.5
Intermittent
(3 x 440-500 V) [A]
- 1.9 2.6 3.4 4.3 5.4 7.7 10.1 - 13.1 17.6 23.2
Continuous KVA
(400 V AC) [KVA]
- 0.9 1.3 1.7 2.1 2.8 3.9 5.0 - 6.9 9.0 11.0
Continuous KVA
(460 V AC) [KVA]
- 0.9 1.3 1.7 2.4 2.7 3.8 5.0 - 6.5 8.8 11.6
Max. cable size
(mains, motor, brake)
[AWG]
2
,[mm
2
]
-
24 - 10 AWG
(0.2 - 4 mm
2
)
-
24 - 10 AWG
(0.2 - 4 mm
2
)
Max. input current
Continuous
(3 x 380-440 V) [A]
- 1.2 1.6 2.2 2.7 3.7 5.0 6.5 - 9.0 11.7 14.4
Intermittent
(3 x 380-440 V) [A]
- 1.9 2.6 3.5 4.3 5.9 8.0 10.4 - 14.4 18.7 23.0
Continuous
(3 x 440-500 V) [A]
- 1.0 1.4 1.9 2.7 3.1 4.3 5.7 - 7.4 9.9 13.0
Intermittent
(3 x 440-500 V) [A]
- 1.6 2.2 3.0 4.3 5.0 6.9 9.1 - 11.8 15.8 20.8
Max. pre-fuses
1
[A] - 10 10 10 10 10 20 20 - 20 32 32
Environment
Estimated pow er loss
at rated max. load [HP,
kW]
- 56 64 72 87 104 123 153 - 190 246 321
Enclosure IP 20
Weight,
enclosure IP20 [lb, kg]
- 4.7 4.7 4.8 4.8 4.9 4.9 4.9 - 4.9 6.6 6.6
Efficiency - 0.94 0.95 0.96 0.97 0.97 0.97 0.97 - 0.98 0.97 0.97
1. FortypeoffuseseesectionFuses.
2. American Wire Gauge.
3. Measured using 16 ft (5 m) shielded motor cables at rated l oad and rated frequency.
75
MG.33.B3.22 - VLT is a registered Danfoss trademark
