Symptom
Possible cause
Test
Solution
Local
Remote or bus reference?
Preset reference active?
Terminal connection correct?
Scaling of terminals correct?
Reference signal available?
3-1* References. Check for correct wir-
ing. Check scaling of terminals. Check
reference signal.
Motor running
in wrong direc-
tion
Motor rotation limit.
Check that parameter 4-10 Motor
Speed Direction is programmed cor-
rectly.
Program correct settings.
Active reversing signal.
Check if a reversing command is
programmed for the terminal in
parameter group 5-1* Digital inputs.
Deactivate reversing signal.
Wrong motor phase connec-
tion.
–
Correct motor phase connection, or
set parameter 1-06 Clockwise Direction
to [1] Inverse.
Motor is not
reaching maxi-
mum speed
Frequency limits set wrong.
Check output limits in parameter
4-13 Motor Speed High Limit [RPM],
parameter 4-14 Motor Speed High
Limit [Hz], and parameter 4-19 Max
Output Frequency.
Program correct limits.
Reference input signal not
scaled correctly.
Check reference input signal scal-
ing in parameter group 6-0* Analog
I/O mode and parameter group 3-1*
References.
Program correct settings.
Motor speed
unstable
Possible incorrect parameter
settings.
Check the settings of all motor pa-
rameters, including all motor com-
pensation settings. For closed-loop
operation, check PID settings.
Check settings in parameter group 1-6*
Load Depen. Setting. For closed-loop
operation, check settings in parameter
group 20-0* Feedback.
Motor runs
rough
Possible overmagnetization.
Check for incorrect motor settings
in all motor parameters.
Check motor settings in parameter
groups 1-2* Motor data, 1-3* Adv Motor
Data, and 1-5* Load Indep. Setting.
Motor does not
brake
Possible incorrect settings in
the brake parameters. Ramp-
down times may be too short.
Check brake parameters. Check
ramp time settings.
Check parameter groups 2-0* DC Brake
and 3-0* Reference Limits.
Open power
fuses
Phase-to-phase short.
Motor or panel has a short phase-
to-phase. Check motor and panel
phases for shorts.
Eliminate any shorts detected.
Motor overload.
Motor is overloaded for the appli-
cation.
Perform start-up test and verify that
motor current is within specifications.
If motor current is exceeding the
nameplate full load current, the motor
can run only with reduced load. Re-
view the specifications for the applica-
tion.
Loose connections.
Perform pre-start-up check for
loose connections.
Tighten loose connections.
AQ262139143212en-000301 / 130R0879 | 159Danfoss A/S © 2021.10
Maintenance, Diagnostics, and
Troubleshooting
VLT® AutomationDrive FC 302
Operating Guide
