Danfoss VLT AutomationDrive FC 302

e30bu152.10
1
3
2
4
5
Illustration 1: Possible Configurations for a D9h Enclosed Drive
1
Input filter cabinet (passive harmonic filter or line re-
actor)
2
Drive cabinet
3
Sine-wave filter cabinet
4
Control compartment
5
Input power options
(1)
1
The D9h enclosure does not require an input power options cabinet – the input power options are placed in the drive cabinet.
e30bu067.10
1
2
4
5
3
Illustration 2: Possible Configurations for a D10h Enclosed Drive
1
Input filter cabinet (passive harmonic filter or line re-
actor)
2
Input power options cabinet
(1)
3
Drive cabinet
4
Sine-wave filter cabinet
5
Control compartment
1
If more than 1 input power option is ordered, the D10h enclosed drive requires an input power options cabinet. Otherwise, the single input power
option is placed below the control compartment in the drive cabinet.
AQ262139143212en-000301 / 130R087918 | Danfoss A/S © 2021.10
Product Overview
VLT® AutomationDrive FC 302
Operating Guide
