Danfoss VLT AutomationDrive FC 302

e30bu068.10
1
2
4
3
6
5
3
Illustration 3: Possible Configurations for an E5h or E6h Enclosed Drive
1
Input filter cabinet (passive harmonic filter or line re-
actor)
2
Input power options cabinet
3
Drive cabinet
4
Sine-wave filter cabinet
5
Control compartment
6
dU/dt filter cabinet
AQ262139143212en-000301 / 130R0879 | 19Danfoss A/S © 2021.10
Product Overview
VLT® AutomationDrive FC 302
Operating Guide
