Danfoss VLT AutomationDrive FC 302 User Manual

Table 21: Protection Rating Codes
Character position
Code
Description
26–27
21
IP21
54
IP54
Table 22: Door-mounted Codes
Character posi-
tion
Code
Description
28–29
XX
None
D1
Signal lights and reset button
D2
Emergency switch off + emergency push-button
D3
STO with emergency push-button (basic functional safety)
D4
STO/SS1 with emergency push-button + safely limited speed (TTL encoder)
D5
STO/SS1 with emergency push-button + safely limited speed (HTL encoder)
DA
Indicator lights and reset button + emergency switch off and emergency push-button
DB
Indicator lights and reset button + STO with emergency push-button (basic functional safety)
DC
Indicator lights and reset button + STO/SS1 with emergency push-button + safely limited speed
(TTL encoder)
DE
Indicator lights and reset button + STO/SS1 with emergency push-button + safely limited speed
(HTL encoder)
Table 23: A Option Codes
Character position
Code
Description
30
X
No A option
0
VLT® PROFIBUS DP-V1 MCA 101
4
VLT® DeviceNet MCA 104 (FC 102/FC 202/FC 302 only)
6
VLT® CANopen MCA 105 (FC 302 only)
8
VLT® EtherCAT MCA 124 (FC 302 only)
G
VLT® LonWorks MCA 108 (FC 102 only)
J
VLT® BACnet MCA 109 (FC 102 only)
K
VLT® BACnet/IP MCA 125 (FC 102 only)
L
VLT® PROFINET MCA 120
N
VLT® EtherNet/IP MCA 121 (FC 102/FC 202/FC 302 only)
Q
VLT® Modbus TCP MCA 122 (FC 102/FC 202/FC 302 only)
T
VLT® PROFIBUS Converter VLT 3000 MCA 113 (FC 302 only)
U
VLT® PROFIBUS Converter VLT 5000 MCA 114 (FC 302 only)
AQ262139143212en-000301 / 130R0879 | 29Danfoss A/S © 2021.10
