Table 51: Option C0 Terminal Connections for VLT® Synchronizing Controller MCO 350
Option card terminal
Corresponding terminal within the control compartment
X55.1
XDW.1
X55.2
XDW.2
X55.3
XDW.3
X55.4
XDW.4
X55.5
XDW.5
X55.6
XDW.6
X55.7
XDW.7
X55.8
XDW.8
X55.9
XDW.9
X55.10
XDW.10
X55.11
XDW.11
X55.12
XDW.12
X56.1
XDW.13
X56.2
XDW.14
X56.3
XDW.15
X56.4
XDW.16
X56.5
XDW.17
X56.6
XDW.18
X56.7
XDW.19
X56.8
XDW.20
X56.9
XDW.21
X56.10
XDW.22
X56.11
XDW.23
X56.12
XDW.24
X57.1
XDW.27
X57.2
XDW.28
X57.3
XDW.29
X57.4
XDW.30
X57.5
XDW.31
X57.6
XDW.32
X57.7
XDW.33
X57.8
XDW.34
