4 Control
4.1 PDO Communication
The real-time data transfer is performed by process data objects (PDO).
The PDOs correspond to entries in the device object dictionary and provide the interface to the application objects.
Illustration 4.1 PDO Types
NOTICE
Control word (CTW), status word (STW), reference (REF), and Main Actual Value (MAV) are xed in PDO type 1–3. PDO
type 4 is free congurable.
All receive and transmit PDOs can be congured via the OD.
Map process data into receive and transmit PDOs via parameter 10-50 Process Data Cong Write. and parameter 10-51 Process
Data Cong Read. or via OD: 1600–1603 for receive PDOs and OD: 1A00–1A03 for transmit PDOs.
