Table 6: Typical Values Measured at a Distance of 1 m (3.28 ft) from the Unit
Enclosure
Level [dBA]
(1)
H3
53.8
H4
64
H5
63.7
H6
71.5
1
The values are measured under the background of 35 dBA noise and the fan running at full speed.
4.9 Mechanical Dimensions
4.9.1 Drive Dimensions
e
f
a
e
e
f
a
d
e
A
a
b
B
C
D
e30bf984.10
Illustration 17: Dimensions
Table 7: Dimensions, Enclosure Sizes H3–H6
Enclosure Size
H3
H4
H5
H6
IP class
IP20
IP20
IP20
IP20
Power [kW (hp)]
3x200–240 V
–
6.0–7.5
(8.0–10)
10 (15)
–
3x380–480 V
6.0–7.5
(8.0–10)
10
(15)
18.5–22
(25–30)
30 (40)
Height [mm (in)]
A
255 (10.0)
296 (11.7)
334 (13.1)
518 (20.4)
A
(1)
329 (13.0)
359 (14.1)
402 (15.8)
595 (23.4)/635 (25), 45 kW
a
240 (9.4)
275 (10.8)
314 (12.4)
495 (19.5)
Width [mm (in)]
B
100 (3.9)
135 (5.3)
150 (5.9)
239 (9.4)
b
74 (2.9)
105 (4.1)
120 (4.7)
200 (7.9)
Depth [mm (in)]
C
206 (8.1)
241 (9.5)
255 (10)
242 (9.5)
Mounting hole [mm (in)]
d
11 (0.43)
12.6 (0.50)
12.6 (0.50)
–
AJ330233902305en-000201 / 130R0596 | 33Danfoss A/S © 2021.05
Specifications
VLT® Compressor Drive CDS 803
Design Guide
