7 How to Order
7.1 Drive Configurator
C D S P T H
e30bd938.11
X S A B CX X X X
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 302221 23 272524 26 28 29 31 373635343332 38 39
X0 D
8
3
X
X
X
X
X
X
X
X X
Illustration 48: Type Code Example
Configure the right drive for the right application from the internet-based Drive Configurator and generate the type code string.
The Drive Configurator automatically generates an 8-digit sales number to be delivered to the local sales office. Furthermore, it is
possible to establish a project list with several products and send it to a Danfoss sales representative.
The Drive Configurator can be found on the global website: www.danfoss.com/drives.
7.2 Type Code Description
Table 26: Type Code Descriptions
Position
Description
Options
01–06
Product group
CDS 803
07–10
Power rating
6.0–30 kW (8.0–40 hp)
11
Number of phases
3
11–12
Mains voltage
T2: 200–240 V AC
T4: 380–480 V AC
13–15
Enclosure
E20: IP20/Chassis
16–17
RFI
H2: RFI filter class A2
H4: RFI filter class A1
18
Brake
X: No brake chopper included
19
Display
A: Alpha-numeric LCP
X: No LCP
20
Coating PCB
X: Not coated PCB (Class 3C2)
C: Coated PCB (Class 3C3)
21
Mains option
X: No mains option
22–23
Adaptation
X: No adaptation
24–27
Software release
SXXX: Latest release in combination with UL 508C
S096: Latest release in combination with UL/EN/IEC 60730-1
28
Software language
X: Standard
29–30
A options
AX: No A options
31–32
B options
BX: No B options
33–34
C0 options
CX: No C options
AJ330233902305en-000201 / 130R0596 | 67Danfoss A/S © 2021.05
How to Order
VLT® Compressor Drive CDS 803
Design Guide
