7.2.2.3 Command Examples
Byte Value Description
Command: Start a soft starter
0
•
0b11000000 (0XC0)
or
•
0b01000000 (0X40)
0bX1000000, where X is 0 or 1 in the reset eld.
Command: Select primary or secondary motor settings
1
•
0b00000000 (0X0)
or
•
0b00100000 (0X20)
Select primary motor settings.
Select secondary motor settings.
Command: Reset a soft starter
0
•
0b11000000 (0XC0)
or
•
0b10000000 (0X80)
The reset only occurs when the previous reset bit is 0, otherwise the value of 1 is ignored.
Command: Stop a soft starter
0 0bX0000000
Table 7.4 Control Commands
7.2.3 Status Information
7.2.3.1 Reading Status Information from the Soft Starter
The EtherNet/IP Module uses input assembly instance 154d in assembly class 0X04 to send status information to the
controller. This instance is the only valid assembly instance.
Byte Function Details
0
Status word
See chapter 7.2.3.2 Status Word (Read-only) for details.
1
2
Reserved
Must be 0.
3
4
Motor current
Measured current is represented as a 32-bit value to 2 decimal places:
0000001 hex = 0.01 A
0000064 hex = 1.00 A
0010D47 hex = 689.35 A
5
6
7
8
Trip code
See chapter 7.2.3.3 Trip Codes.
9
10
Reserved
Must be 0.
11
Table 7.5 Status Information
Packet Structures EtherNet/IP Module
14 Danfoss A/S © 05/2017 All rights reserved. MG17Q102
