7.3 Acyclic Operation
This section provides information on objects, instances,
and attributes for acyclic operation. It also lists the
requirements related to acyclic services for the EtherNet/IP
Module.
7.3.1 Class 0X01 Identity Object
The EtherNet/IP Module supports the attributes for identity
objects listed in Table 7.8.
Attribute Function Description
1 Vendor Supported
2 Device type The attribute value is 12d
3 Product code Supported
4 Revision: Major,
minor
Revision value set in the EDS le
5 Status Status of the netIC module
6 Serial number Serial number of the netIC
module
7 Product name Supported
Table 7.8 Identity Object Attributes
7.3.2 Vendor-specic Objects
The EtherNet/IP Module supports vendor-specic class
objects 100, 101, 103, and 104.
7.3.2.1 Class 100 Objects (Read/Write)
Object name Class Instance Attribute
Motor full load current 100 101 100
Locked rotor time 100 102 100
Start mode 100 103 100
Current limit 100 104 100
Initial current 100 105 100
Start ramp time 100 106 100
Kickstart level 100 107 100
Kickstart time 100 108 100
Excess start time 100 109 100
Stop mode 100 110 100
Stop time 100 111 100
Adaptive control gain 100 112 100
Adaptive start prole 100 113 100
Adaptive stop prole 100 114 100
Brake torque 100 115 100
Brake time 100 116 100
Phase sequence 100 117 100
Current imbalance 100 118 100
Current imbalance delay 100 119 100
Undercurrent 100 120 100
Undercurrent delay 100 121 100
Object name Class Instance Attribute
Instantaneous overcurrent 100 122 100
Instantaneous overcurrent delay 100 123 100
Frequency check 100 124 100
Frequency variation 100 125 100
Frequency delay 100 126 100
Restart delay 100 127 100
Motor temperature check 100 128 100
Local/remote 100 129 100
Comms in remote 100 130 100
Input A function 100 131 100
Input A name 100 132 100
Input A trip 100 133 100
Input A trip delay 100 134 100
Input A initial delay 100 135 100
Remote reset logic 100 136 100
Relay A function 100 137 100
Relay A on delay 100 138 100
Relay A o delay 100 139 100
Relay B function 100 140 100
Relay B on delay 100 141 100
Relay B o delay 100 142 100
Relay C function 100 143 100
Relay C on delay 100 144 100
Relay C o delay 100 145 100
Low current ag 100 146 100
High current ag 100 147 100
Motor temperature ag 100 148 100
Analog output A 100 149 100
Analog A scale 100 150 100
Analog A maximum adjustment 100 151 100
Analog A minimum adjustment 100 152 100
Auto-start type 100 153 100
Auto-start time 100 154 100
Auto-stop type 100 155 100
Auto-stop time 100 156 100
Auto-reset action 100 157 100
Maximum resets 100 158 100
Reset delay groups A&B 100 159 100
Reset delay group C 100 160 100
Motor FLC-2 100 161 100
Locked rotor time-2 100 162 100
Start mode-2 100 163 100
Current limit-2 100 164 100
Initial current-2 100 165 100
Start ramp-2 100 166 100
Kickstart level-2 100 167 100
Kickstart time-2 100 168 100
Excess start time-2 100 169 100
Stop mode-2 100 170 100
Stop time-2 100 171 100
Adaptive control gain-2 100 172 100
Adaptive start prole-2 100 173 100
Adaptive stop prole-2 100 174 100
Packet Structures Installation Guide
MG17Q102 Danfoss A/S © 05/2017 All rights reserved. 17
