5.5. Reading/Writing to Parameters with Index
Indexed parameters such as 10-11 or 10-12 need special handling since DeviceNet does not sup-
port indexed addressing. The way to handle this in the frequency converter is to use par. 10-30
Parameter Data Types , which serves as an index pointer. Set up the pointer before each read/
write of an indexed parameter.
NB!
If two masters access this feature at the same time, incorrect data may be gener-
ated.
5.5.1. Example
Write 16-10 in index 2 in par. 10-12 Process Data Config Read .
First, set up the index pointer in par. 10-30
Array Index . In this example index 2:
The next step is to write the data (in this ex-
ample 16-10) to par. 10-12.
Class Instance Attribute Value
110 Dec 1 Dec 130 Dec 2 Dec
6E Hex 1 Hex 82 Hex 2 Hex
Class Instance Attribute Value
110 Dec 1 Dec 112 Dec 1610 Dec
6E Hex 1 Hex 70 Hex 64A Hex
FC 100/ 200/ 300 DeviceNet 5. How to Access the Parameters
MG.33.D3.02 - VLT
®
is a registered Danfoss trademark 51
