Danfoss vlt fcd 302 - Illustration 2.16 PE Connection between the Installation Box and the Electronic Part

CAUTION
PE CONNECTION
The metal pins in
the corners of the electronic part and
the holes on the corner of the installation box are essential
for the protective earth connection. Make sure that they
are not loosened, removed, or violated in any way.
Tightening torque requirement is 3 Nm. See
Illustration 2.16.
130BC391.10
Illustration 2.16 PE Connection between the Installation Box and
the Electronic Part
NOTE
The external
grounding terminal
is available as an
accessory (part no: 130B5833).
Installation
VLT
®
Decentral Drive FCD 302 Operating Instructions
