5.3 Parameter Lists
Changes during operation
”TRUE”
means
that
the
parameter can be changed while
the frequency converter is in operation and “FALSE” means
that it must be stopped before a change can be made.
4-Set-up
'All set-up': the parameters
can be set individually in each
of the four set-ups, that is, one single parameter can have
four different data values.
In all set-ups ’1 set-up’: data value is the same.
Conversion index
This number refers to
a conversion figure used when
writing or reading to and from the frequency converter.
Conv. index Conv. factor
100 1
67 1/60
6 1000000
5 100000
4 10000
3 1000
2 100
1 10
0 1
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
-5 0.00001
-6 0.000001
Data
type
Description Type
2 Integer 8 Int8
3 Integer 16 Int16
4 Integer 32 Int32
5 Unsigned 8 Uint8
6 Unsigned 16 Uint16
7 Unsigned 32 Uint32
9 Visible String VisStr
33 Normalized value 2 bytes N2
35 Bit sequence of 16 boolean variables V2
54 Time difference w/o date TimD
See the FCD 302 Design Guide,
MG04HXYY for further
information about data types 33, 35 and 54.
Parameters for the frequency converter are grouped into
various parameter groups for easy selection of the correct
parameters for optimized operation of the frequency
converter.
0-** Operation and Display parameters for basic
frequency converter settings
1-** Load
and Motor parameters
2-** Brakes
3-** References and ramping parameters, includes
DigiPot function
4-** Limits Warnings, setting of limits and
warning parameters
5-** Digital inputs and outputs, includes relay
controls
6-** Analog inputs and outputs
7-** Controls, setting parameters for speed and
process controls
8-** Communication and option parameters,
setting of FC RS-485-485 and FC USB port
parameters.
9-** Profibus
13-** Smart Logic Control parameters
14-** Special function parameters
15-** Drive information parameters
16-** Read out parameters
17-** Motor Feedback Option parameters
30-** Special Features
Programming
VLT
®
Decentral Drive FCD 302 Operating Instructions
40 MG04F302 - VLT
®
is a registered Danfoss trademark
55
