Parameter description Default value 4-set-up Change
during
operation
Conver-
sion
index
Type
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation 100% All set-ups TRUE 0 Int16
1-61 High Speed Load Compensation 100% All set-ups TRUE 0 Int16
1-62 Slip Compensation App.Dependent All set-ups TRUE 0 Int16
1-63 Slip Compensation Time Constant App.Dependent All set-ups TRUE -2 Uint16
1-64 Resonance Dampening 100% All set-ups TRUE 0 Uint16
1-65 Resonance Dampening Time Constant 5 ms All set-ups TRUE -3 Uint8
1-66 Min. Current at Low Speed 100% All set-ups TRUE 0 Uint8
1-67 Load Type [0] Passive load All set-ups TRUE - Uint8
1-68 Minimum Inertia App.Dependent All set-ups FALSE -4 Uint32
1-69 Maximum Inertia App.Dependent All set-ups FALSE -4 Uint32
1-7* Start Adjustments
1-71 Start Delay 0.0 s All set-ups TRUE -1 Uint8
1-72 Start Function [2] Coast/delay time All set-ups TRUE - Uint8
1-73 Flying Start null All set-ups FALSE - Uint8
1-74 Start Speed [RPM] App.Dependent All set-ups TRUE 67 Uint16
1-75 Start Speed [Hz] App.Dependent All set-ups TRUE -1 Uint16
1-76 Start Current 0.00 A All set-ups TRUE -2 Uint32
1-8* Stop Adjustments
1-80 Function at Stop [0] Coast All set-ups TRUE - Uint8
1-81 Min Speed for Function at Stop [RPM] App.Dependent All set-ups TRUE 67 Uint16
1-82 Min Speed for Function at Stop [Hz] App.Dependent All set-ups TRUE -1 Uint16
1-83 Precise Stop Function [0] Precise ramp stop All set-ups FALSE - Uint8
1-84 Precise Stop Counter Value 100000 N/A All set-ups TRUE 0 Uint32
1-85 Precise Stop Speed Compensation Delay 10 ms All set-ups TRUE -3 Uint8
1-9* Motor Temperature
1-90 Motor Thermal Protection [0] No protection All set-ups TRUE - Uint8
1-91 Motor External Fan [0] No All set-ups TRUE - Uint16
1-93 Thermistor Resource [0] None All set-ups TRUE - Uint8
1-94 ATEX ETR cur.lim. speed reduction 0.0% 2 set-ups TRUE -1 Uint16
1-95 KTY Sensor Type [0] KTY Sensor 1 All set-ups TRUE - Uint8
1-96 KTY Thermistor Resource [0] None All set-ups TRUE - Uint8
1-97 KTY Threshold level 80
º
C 1 set-up TRUE 100 Int16
1-98 ATEX ETR interpol. points freq. App.Dependent 1 set-up TRUE -1 Int16
1-99 ATEX ETR interpol points current App.Dependent 2 set-ups TRUE 0 Int16
Programming
VLT
®
Decentral Drive FCD 302 Operating Instructions
