Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
5-6* Pulse Output
5-60 Terminal 27 Pulse Output Variable null All set-ups TRUE - Uint8
5-62 Pulse Output Max Freq #27 App.Dependent All set-ups TRUE 0 Uint32
5-63 Terminal 29 Pulse Output Variable null All set-ups TRUE - Uint8
5-65 Pulse Output Max Freq #29 App.Dependent All set-ups TRUE 0 Uint32
5-7* 24V Encoder Input
5-70 Term 32/33 Pulses per Revolution 1024 N/A All set-ups FALSE 0 Uint16
5-71 Term 32/33 Encoder Direction [0] Clockwise All set-ups FALSE - Uint8
5-8* I/O Options
5-80 AHF Cap Reconnect Delay 25 s 2 set-ups TRUE 0 Uint16
5-9* Bus Controlled
5-90 Digital & Relay Bus Control 0 N/A All set-ups TRUE 0 Uint32
5-93 Pulse Out #27 Bus Control 0.00% All set-ups TRUE -2 N2
5-94 Pulse Out #27 Timeout Preset 0.00% 1 set-up TRUE -2 Uint16
5-95 Pulse Out #29 Bus Control 0.00% All set-ups TRUE -2 N2
5-96 Pulse Out #29 Timeout Preset 0.00% 1 set-up TRUE -2 Uint16
Programming
VLT
®
Decentral Drive FCD 302 Operating Instructions
MG04F302 - VLT
®
is a registered Danfoss trademark
49
5 5
