5.3.11 13-** Smart Logic
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
13-0* SLC Settings
13-00 SL Controller Mode null 2 set-ups TRUE - Uint8
13-01 Start Event null 2 set-ups TRUE - Uint8
13-02 Stop Event null 2 set-ups TRUE - Uint8
13-03 Reset SLC [0] Do not reset SLC All set-ups TRUE - Uint8
13-1* Comparators
13-10 Comparator Operand null 2 set-ups TRUE - Uint8
13-11 Comparator Operator null 2 set-ups TRUE - Uint8
13-12 Comparator Value App.Dependent 2 set-ups TRUE -3 Int32
13-1* RS Flip Flops
13-15 RS-FF Operand S null 2 set-ups TRUE - Uint8
13-16 RS-FF Operand R null 2 set-ups TRUE - Uint8
13-2* Timers
13-20 SL Controller Timer App.Dependent 1 set-up TRUE -3 TimD
13-4* Logic Rules
13-40 Logic Rule Boolean 1 null 2 set-ups TRUE - Uint8
13-41 Logic Rule Operator 1 null 2 set-ups TRUE - Uint8
13-42 Logic Rule Boolean 2 null 2 set-ups TRUE - Uint8
13-43 Logic Rule Operator 2 null 2 set-ups TRUE - Uint8
13-44 Logic Rule Boolean 3 null 2 set-ups TRUE - Uint8
13-5* States
13-51 SL Controller Event null 2 set-ups TRUE - Uint8
13-52 SL Controller Action null 2 set-ups TRUE - Uint8
Programming
VLT
®
Decentral Drive FCD 302 Operating Instructions
54 MG04F302 - VLT
®
is a registered Danfoss trademark
55
