5.3.14 16-** Data Readouts
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
16-0* General Status
16-00 Control Word 0 N/A All set-ups FALSE 0 V2
16-01 Reference [Unit] 0.000 ReferenceFeedbackUnit All set-ups FALSE -3 Int32
16-02 Reference % 0.0% All set-ups FALSE -1 Int16
16-03 Status Word 0 N/A All set-ups FALSE 0 V2
16-05 Main Actual Value [%] 0.00% All set-ups FALSE -2 N2
16-09 Custom Readout 0.00 CustomReadoutUnit All set-ups FALSE -2 Int32
16-1* Motor Status
16-10 Power [kW] 0.00 kW All set-ups FALSE 1 Int32
16-11 Power [hp] 0.00 hp All set-ups FALSE -2 Int32
16-12 Motor Voltage 0.0 V All set-ups FALSE -1 Uint16
16-13 Frequency 0.0 Hz All set-ups FALSE -1 Uint16
16-14 Motor Current 0.00 A All set-ups FALSE -2 Int32
16-15 Frequency [%] 0.00% All set-ups FALSE -2 N2
16-16 Torque [Nm] 0.0 Nm All set-ups FALSE -1 Int16
16-17 Speed [RPM] 0 RPM All set-ups FALSE 67 Int32
16-18 Motor Thermal 0% All set-ups FALSE 0 Uint8
16-19 KTY sensor temperature 0
º
C All set-ups FALSE 100 Int16
16-20 Motor Angle 0 N/A All set-ups TRUE 0 Uint16
16-21 Torque [%] High Res. 0.0% All set-ups FALSE -1 Int16
16-22 Torque [%] 0% All set-ups FALSE 0 Int16
16-25 Torque [Nm] High 0.0 Nm All set-ups FALSE -1 Int32
16-3* Drive Status
16-30 DC Link Voltage 0 V All set-ups FALSE 0 Uint16
16-32 Brake Energy /s 0.000 kW All set-ups FALSE 0 Uint32
16-33 Brake Energy /2 min 0.000 kW All set-ups FALSE 0 Uint32
16-34 Heatsink Temp. 0
º
C All set-ups FALSE 100 Uint8
16-35 Inverter Thermal 0% All set-ups FALSE 0 Uint8
16-36 Inv. Nom. Current App.Dependent All set-ups FALSE -2 Uint32
16-37 Inv. Max. Current App.Dependent All set-ups FALSE -2 Uint32
16-38 SL Controller State 0 N/A All set-ups FALSE 0 Uint8
16-39 Control Card Temp. 0
º
C All set-ups FALSE 100 Uint8
16-40 Logging Buffer Full [0] No All set-ups TRUE - Uint8
16-41 LCP Bottom Statusline 0 N/A All set-ups TRUE 0
VisStr[5
0]
16-49 Current Fault Source 0 N/A All set-ups TRUE 0 Uint8
16-5* Ref. & Feedb.
16-50 External Reference 0.0 N/A All set-ups FALSE -1 Int16
16-51 Pulse Reference 0.0 N/A All set-ups FALSE -1 Int16
16-52 Feedback [Unit] 0.000 ReferenceFeedbackUnit All set-ups FALSE -3 Int32
16-53 Digi Pot Reference 0.00 N/A All set-ups FALSE -2 Int16
16-57 Feedback [RPM] 0 RPM All set-ups FALSE 67 Int32
Programming
VLT
®
Decentral Drive FCD 302 Operating Instructions
MG04F302 - VLT
®
is a registered Danfoss trademark
59
5 5
