Table 52: Option C1 Terminal Connections for VLT® Advanced Cascade Controller MCO 102
Option card terminal
Corresponding terminal within the control compartment
X67.1
XDF.21
X67.2
XDF.22
X67.3
XDF.23
X67.4
XDF.24
X67.5
XDF.25
X67.6
XDF.26
X67.7
XDF.27
X67.8
XDF.28
X67.9
XDF.29
X67.10
XDF.30
X67.11
XDF.31
X67.12
XDF.32
X66.1
XDF.1
X66.2
XDF.2
X66.3
XDF.3
X66.4
XDF.4
X66.5
XDF.5
X66.6
XDF.6
X66.7
XDF.7
X66.8
XDF.8
X66.9
XDF.9
X66.10
XDF.10
X66.11
XDF.11
X66.12
XDF.12
X66.13
XDF.13
X66.14
XDF.14
X58.1
XDF.15
X58.2
XDF.16
