Danfoss VLT Midi Drive FC 280 Instruction Manual

Enclosure size Power [kW] (hp) CE compliance fuse LVD circuit breaker
K1
0.37–2.2 (0.5–3)
gG-10 PKZM0-16
K2
3.0–5.5 (4–7.5)
gG-25 PKZM0-20
K3 7.5 (10) gG-32 PKZM0-25
K4 11–15 (15–20) gG-50
K5 18.5–22 (25–30) gG-80
Table 9.4 CE Fuse, 380–480 V
9.9 Enclosure Sizes, Power Ratings and Dimensions
See Figure 3.2 for the dimensions, and the top and bottom mounting holes.
Enclosure size K1 K2 K3 K4 K5
Power Size
[kW (hp)]
Single-phase
200–240 V
0.37
(0.5)
0.55
(0.75)
0.75
(1.0)
1.1
(1.5)
1.5 (2.0) 2.2 (3.0) – – –
3-phase
200–240 V
0.37
(0.5)
0.55
(0.75)
0.75
(1.0)
1.1
(1.5)
1.5 (2.0) 2.2 (3.0) 3.7 (5) – –
3-phase
380–480 V
0.37
(0.5)
0.55
(0.75)
0.75
(1.0)
1.1
(1.5)
1.5
(2.0)
2.2
(3.0)
3
(4)
4 (5) 5.5
(7.5)
7.5 (10) 11
(15)
15
(20)
18.5
(25)
22
(30)
Dimensions
[mm] (in)
Height A 210 (8.27) 272.5 (10.73) 272.5
(10.73)
317.5
(12.5)
410 (16.14)
Width B 75 (2.95) 90 (3.54) 115
(4.53)
133 (5.24) 150 (5.91)
Depth C
168 (6.61) 168 (6.61)
168
(6.61)
245 (9.65) 245 (9.65)
Mounting
holes
a 198 (7.8) 260 (10.24) 260
(10.24)
297.5
(11.71)
390 (15.35)
b 60 (2.36) 70 (2.76) 90 (3.54) 105 (4.13) 120 (4.72)
c 5 (0.2) 6.4 (0.25) 6.5
(0.26)
8 (0.315) 7.8 (0.307)
d 9 (0.35) 11 (0.43) 11 (0.43) 12.4
(0.488)
12.6 (0.496)
e 4.5 (0.177) 5.5 (0.22) 5.5
(0.22)
6.8 (0.27) 7 (0.28)
f 7.3 (0.287) 8.1 (0.319) 9.2
(0.362)
11 (0.43) 11.2 (0.44)
Table 9.5 Enclosure Sizes, Power Ratings and Dimensions
Specications Instruction Manual
MG07A122 Danfoss A/S © 11/2015 All rights reserved. 55
9 9
