Danfoss VLT series Quick Guide

Parameter Range Default Function
0-03 Regional Settings [0] International
[1] US
0
0-06 GridType [0] 200-240 V/50 Hz/IT-grid
[1] 200-240 V/50 Hz/Delta
[2] 200-240 V/50 Hz
[10] 380-440 V/50 Hz/IT-grid
[11] 380-440 V/50 Hz/Delta
[12] 380-440 V/50 Hz
[20] 440-480 V/50 Hz/IT-grid
[21] 440-480 V/50 Hz/Delta
[22] 440-480 V/50 Hz
[30] 525-600 V/50 Hz/IT-grid
[31] 525-600 V/50 Hz/Delta
[32] 525-600 V/50 Hz
[100] 200-240 V/60 Hz/IT-grid
[101] 200-240 V/60 Hz/Delta
[102] 200-240 V/60 Hz
[110] 380-440 V/60 Hz/IT-grid
[111] 380-440 V/60 Hz/Delta
[112] 380-440 V/60 Hz
[120] 440-480 V/60 Hz/IT-grid
[121] 440-480 V/60 Hz/Delta
[122] 440-480 V/60 Hz
[130] 525-600 V/60 Hz/IT-grid
[131] 525-600 V/60 Hz/Delta
[132] 525-600 V/60 Hz
Size related
Select operating mode for restart upon
reconnection of the drive to mains voltage after
power down.
1-20 Motor Power 0.12-110 kW/0.16-150 hp Size related Enter motor power from nameplate data.
1-22 Motor Voltage 50.0-1000.0 V Size related Enter motor voltage from nameplate data.
1-23 Motor Frequency 20.0-400.0 Hz Size related Enter motor frequency from nameplate data.
1-24 Motor Current 0.01-10000.00 A Size related Enter motor current from nameplate data.
1-25 Motor Nominal
Speed
100.0-9999.0 RPM Size related Enter motor nominal speed from nameplate data
1-26 Torque nominal do
Motor
0.1-1000.0 Size related This parameter is available only when
1-10 Construção do Motor Design is set to [1] PM,
non-salient SPM .
NOTE
Changing this parameter will affect settings
of other parameters.
1-29 Automatic Motor
Adaption (AMA)
See 1-29 Automatic Motor
Adaption (AMA)
Off Performing an AMA optimizes motor performance.
1-30 Resistência do
Estator (Rs)
0.000-99.990 Size related Set the stator resistance value.
1-37 Indutância do eixo-d
(Ld)
0-1000 Size related Enter the value of the d-axis inductance.
Obtain the value from the permanent magnet
motor data sheet. The de-axis inductance cannot
be found by performing an AMA.
1-39 Pólos do Motor 2-100 4 Enter the number of motor poles.
1-40 Força Contra Eletro-
motriz em 1000RPM
10-9000 Size related Line-Line RMS back EMF voltage at 1000 RPM.
1-73 Flying Start When PM is selected, Flying Start is enabled and
can not disable.
Quick Guide
VLT
®
HVAC Basic Drive Cascade Controller Quick Guide
MG18F402 - VLT
®
is a registered Danfoss trademark 15
1 1
