Danfoss VLT series Quick Guide

Parameter Range Default Function
0-03 Regional Settings [0] International
[1] US
0
0-06 GridType [0] -[[132] see start -up wizard
for open loop application
Size selected Select operating mode for restart upon
reconnection of the frequency converter to
mains voltage after power down.
1-00 Configuration Mode [0] Open loop
[3] Closed loop
0 Change this parameter to Closed loop.
1-20 Motor Power 0.09-110 kW Size related Enter motor power from nameplate data.
1-22 Motor Voltage 50.0-1000.0 V Size related Enter motor voltage from nameplate data.
1-23 Motor Frequency 20.0-400.0 Hz Size related Enter motor frequency from nameplate data.
1-24 Motor Current 0.0 -10000.00 A Size related Enter motor current from nameplate data.
1-25 Motor Nominal Speed 100.0-9999.0 RPM Size related Enter motor nominal speed from nameplate
data.
1-26 Torque nominal do Motor 0.1-1000.0 Size related This parameter is available only when
1-10 Construção do Motor Design is set to [1]
PM, non-salient SPM.
NOTE
Changing this parameter affects settings
of other parameters.
1-29 Automatic Motor Adaption
(AMA)
Off Performing an AMA optimizes motor
performance.
1-30 Resistência do Estator (Rs) 0.000-99.990 Size related Set the stator resistance value.
1-37 Indutância do eixo-d (Ld) 0-1000 Size related Enter the value of the d-axis inductance.
Obtain the value from the permanent magnet
motor data sheet. The de-axis inductance
cannot be found by performing an AMA.
1-39 Pólos do Motor 2-100 4 Enter the number of motor poles.
1-40 Força Contra Eletromotriz em
1000RPM
10-9000 Size related Line-Line RMS back EMF voltage at 1000 RPM.
1-73 Flying Start [0] Disabled
[1] Enabled
0
Select [1] Enable to enable the frequency
converter to catch a spinning motor. I.e. fan
applications. When PM is selected, Flying Start
is enabled.
3-02 Minimum Reference -4999-4999 0 The minimum reference is the lowest value
obtainable by summing all references.
3-03 Maximum Reference -4999-4999 50 The maximum reference is the highest value
obtainable by summing all references.
3-10 Preset Reference -100-100% 0 Enter the set point.
3-41 Ramp 1 Ramp Up Time 0.05-3600.0 s Size related Ramp up time from 0 to rated 1-23 Motor
Frequency if Asynchron motor is selected;
ramp up time from 0 to 1-25 Motor Nominal
Speed if PM motor is selected".
3-42 Ramp 1 Ramp Down Time 0.05-3600.0 s Size related Ramp down time from rated 1-23 Motor
Frequency to 0 if Asynchron motor is selected;
ramp down time from 1-25 Motor Nominal
Speed to 0 if PM motor is selected.
4-12 Motor Speed Low Limit [Hz] 0.0-400 Hz 0.0 Hz Enter the minimum limit for low speed.
4-14 Motor Speed High Limit [Hz] 0-400 Hz 65 Hz Enter the minimum limit for high speed.
4-19 Freqüência Máx. de Saída 0-400 Size related Enter the maximum output frequency value.
6-29 Terminal 54 mode [0] Current
[1] Voltage
1 Select if terminal 54 is used for current- or
voltage input.
6-20 Terminal 54 Low Voltage 0-10 V 0.07 V Enter the voltage that corresponds to the low
reference value.
Quick Guide
VLT
®
HVAC Basic Drive Cascade Controller Quick Guide
18 MG18F402 - VLT
®
is a registered Danfoss trademark
11
