Par. No. # Parameter description Default value
(SR = Size related)
4 set-up Change during oper-
ation
Conver-
sion index
Type
8-0* General Settings 8-01 Control Site null All set-ups TRUE - Uint8 8-02 Control Source null All set-ups TRUE - Uint8
8-03 Control Timeout Time ExpressionLimit 1 set-up TRUE -1 Uint32
8-04 Control Timeout Function [0] Off 1 set-up TRUE - Uint8
8-05 End-of-Timeout Function [1] Resume set-up 1 set-up TRUE - Uint8
8-06 Reset Control Timeout [0] Do not reset All set-ups TRUE - Uint8
8-07
Diagnosis Trigger [0] Disable 2 set-ups TRUE - Uint8
8-1* Control Settings 8-10 Control Profile [0] FC profile All set-ups TRUE - Uint8 8-13 Configurable Status Word STW [1] Profile Default All set-ups TRUE - Uint8 8-3* FC Port Settings 8-30 Protocol null 1 set-up TRUE - Uint8 8-31 Address ExpressionLimit 1 set-up TRUE 0 Uint8 8-32 Baud Rate null 1 set-up TRUE - Uint8
8-33 Parity / Stop Bits null 1 set-up TRUE - Uint8
8-35 Minimum Response Delay ExpressionLimit 1 set-up TRUE -3 Uint16
8-36 Max Response Delay ExpressionLimit 1 set-up TRUE -3 Uint16
8-37 Max Inter-Char Delay ExpressionLimit 1 set-up TRUE -5 Uint16 8-4* FC MC protocol set 8-40 Telegram selection [1] Standard telegram 1 2 set-ups TRUE - Uint8 8-5* Digital/Bus 8-50 Coasting Select [3] Logic OR All set-ups TRUE - Uint8 8-52 DC Brake Select [3] Logic OR All set-ups TRUE - Uint8 8-53 Start Select [3] Logic OR All set-ups TRUE - Uint8
8-54 Reverse Select null All set-ups TRUE - Uint8
8-55 Set-up Select [3] Logic OR All set-ups TRUE - Uint8
8-56
Preset Reference Select [3] Logic OR All set-ups TRUE - Uint8
8-7* BACnet 8-70 BACnet Device Instance 1 N/A 1 set-up TRUE 0 Uint32 8-72 MS/TP Max Masters 127 N/A 1 set-up TRUE 0 Uint8
8-73 MS/TP Max Info Frames 1 N/A 1 set-up TRUE 0 Uint16
8-74 "Startup I am" [0] Send at power-up 1 set-up TRUE - Uint8
8-75
Initialization Password ExpressionLimit 1 set-up TRUE 0 VisStr[20]
8-8* FC Port Diagnostics 8-80 Bus Message Count 0 N/A All set-ups TRUE 0 Uint32 8-81 Bus Error Count 0 N/A All set-ups TRUE 0 Uint32
8-82 Slave Message Count 0 N/A All set-ups TRUE 0 Uint32
8-83 Slave Error Count 0 N/A All set-ups TRUE 0 Uint32
8-84 Slave Messages Sent 0 N/A All set-ups TRUE 0 Uint32
8-85 Slave Timeout Errors 0 N/A All set-ups TRUE 0 Uint32
8-89
Diagnostics Count 0 N/A 1 set-up TRUE 0 Int32
8-9* Bus Jog 8-90 Bus Jog 1 Speed 100 RPM All set-ups TRUE 67 Uint16 8-91 Bus Jog 2 Speed 200 RPM All set-ups TRUE 67 Uint16
8-94 Bus Feedback 1 0 N/A 1 set-up TRUE 0 N2
8-95 Bus Feedback 2 0 N/A 1 set-up TRUE 0 N2
8-96 Bus Feedback 3 0 N/A 1 set-up TRUE 0 N2
6.2.9 8-** Communication and Options
6 How to program the adjustable frequency
drive
VLT
®
HVAC Drive Instruction Manual
6-66 MG.11.A9.22 - VLT
®
is a registered Danfoss trademark
6

Danfoss VLT Specifications

General

Frequency	50/60 Hz
Enclosure	IP20, IP21, IP55, IP66
Series	VLT
Control Technique	Flux Vector Control
Output Voltage	0-Vinput
Control Method	Fieldbus
Communication Interface	PROFIBUS, CANopen
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Cooling Method	Liquid Cooled
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% non-condensing
Altitude	Up to 1000m (3280ft) without derating, up to 4000m (13120ft) with derating
Operating Temperature	-10°C to +50°C (14°F to 122°F)
