Load Adjustable Frequency Drive Settings:
1. Connect a PC to the adjustable frequency drive via the USB com port
2. Open MCT 10 Set-up software
3. Choose “Open”– stored files will be shown.
4. Open the appropriate file.
5. Choose “Write to drive.”
All parameter settings are now transferred to the adjustable frequency drive.
A separate manual forMCT 10 Set-up Software is available:
MG.10.Rx.yy
.
The MCT 10 Set-up Software Modules
The following modules are included in the software package:
MCT Set-up 10 Software
Setting parameters
Copy to and from adjustable frequency drives
Documentation and print-out of parameter settings incl. diagrams
Ext. User Interface
Preventive Maintenance Schedule
Clock settings
Timed Action Programming
Smart Logic Controller Set-up
Ordering number:
Please order the CD containing the MCT 10 Set-up software using code number 130B1000.
MCT 10 can also be downloaded from the Danfoss Internet:
WWW.DANFOSS.COM, Business Area: Motion Controls
.
5.1.6 Tips and tricks
* For the majority of HVAC applications, the Quick Menu, Quick Set-up and Function Set-up provide the simplest and quickest
access to all the typical parameters required.
* Whenever possible, performing an AMA will ensure best shaft performance
*
The contrast of the display can be adjusted by pressing [Status] and [
▲
] for a darker display or by pressing [Status] and [
▼
]
for a brighter display
* Under [Quick Menu] and [Changes Made] all parameters that have been changed from the factory settings are displayed
* Press and hold the [Main Menu] key for 3 seconds to access any parameter.
* For service purposes, it is recommended to copy all parameters to the LCP, see par. 0-50
LCP Copy
for further information.
Table 5.1: Tips and tricks
5.1.7 Quick Transfer of Parameter Settings when using GLCP
Once the set-up of an adjustable frequency drive is complete, it is recommended to store (backup) the parameter settings in the GLCP or on a PC via
MCT 10 Set-up Software Tool.
VLT
®
HVAC Drive Instruction Manual
5 How to operate the adjustable frequency
drive
MG.11.A9.22 - VLT
®
is a registered Danfoss trademark
5-5
5
