Danfoss VLT User Manual

Line Power Supply 3 x 525–690 V AC
P500 P560 P630
Typical Shaft output at 550 V
[kW]
400 450 500
Typical Shaft output at 575 V
[HP]
500 600 650
Typical Shaft output at 690 V
[kW]
500 560 630
Enclosure IP21 E1 E1 E1
Enclosure IP54 E1 E1 E1
Enclosure IP00 E2 E2 E2
Output current
Continuous
(at 550 V) [A]
523 596 630
Intermittent (60 sec overload)
(at 550 V) [A]
575 656 693
Continuous
(at 575/690 V) [A]
500 570 630
Intermittent (60 sec overload)
(at 575/690 V) [A]
550 627 693
Continuous KVA
(at 550 V) [KVA]
498 568 600
Continuous KVA
(at 575 V) [KVA]
498 568 627
Continuous KVA
(at 690 V) [KVA]
598 681 753
Max. input current
Continuous
(at 550 V) [A]
504 574 607
Continuous
(at 575 V) [A]
482 549 607
Continuous
(at 690 V) [A]
482 549 607
Max. cable size, line power, mo-
tor and load share [mm
2
(AWG)]
4x240 (4x500 mcm) 4x240 (4x500 mcm) 4x240 (4x500 mcm)
Max. cable size, brake [mm
2
(AWG)]
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
Max. external pre-fuses [A]
1
700 900 900
Estimated power loss
at rated max. load [W]
4)
, 575 V
6903 8343 9244
Estimated power loss
at rated max. load [W]
4)
, 690 V
7249 8727 9673
Weight,
enclosure IP21, IP 54 [kg]
263 272 313
Weight,
enclosure IP00 [kg]
221 236 277
Efficiency
4)
0.98
Output frequency 0–500 Hz
Heatsink overtemp. trip 185°F [85°C]
Power card ambient trip 154°F [68°C]
8 Specifications VLT
®
HVAC Drive Instruction Manual
8-12 MG.11.A9.22 - VLT
®
is a registered Danfoss trademark
8

Danfoss VLT Specifications

General

Frequency	50/60 Hz
Enclosure	IP20, IP21, IP55, IP66
Series	VLT
Control Technique	Flux Vector Control
Output Voltage	0-Vinput
Control Method	Fieldbus
Communication Interface	PROFIBUS, CANopen
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Cooling Method	Liquid Cooled
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% non-condensing
Altitude	Up to 1000m (3280ft) without derating, up to 4000m (13120ft) with derating
Operating Temperature	-10°C to +50°C (14°F to 122°F)
