Par. No. # Parameter description Default value
(SR = Size related)
4 set-up Change during oper-
ation
Conver-
sion index
Type
13-0* SLC Settings 13-00 SL Controller Mode null 2 set-ups TRUE - Uint8 13-01 Start Event null 2 set-ups TRUE - Uint8
13-02 Stop Event null 2 set-ups TRUE - Uint8
13-03 Reset SLC [0] Do not reset SLC All set-ups TRUE - Uint8 13-1* Comparators 13-10 Comparator Operand null 2 set-ups TRUE - Uint8 13-11 Comparator Operator null 2 set-ups TRUE - Uint8 13-12 Comparator Value ExpressionLimit 2 set-ups TRUE -3 Int32 13-2* Timers 13-20 SL Controller Timer ExpressionLimit 1 set-up TRUE -3 TimD 13-4* Logic Rules 13-40 Logic Rule Boolean 1 null 2 set-ups TRUE - Uint8 13-41 Logic Rule Operator 1 null 2 set-ups TRUE - Uint8 13-42 Logic Rule Boolean 2 null 2 set-ups TRUE - Uint8
13-43 Logic Rule Operator 2 null 2 set-ups TRUE - Uint8
13-44 Logic Rule Boolean 3 null 2 set-ups TRUE - Uint8 13-5* States 13-51 SL Controller Event null 2 set-ups TRUE - Uint8 13-52 SL Controller Action null 2 set-ups TRUE - Uint8
6.2.13 13-** Smart Logic Controller
6 How to program the adjustable frequency
drive
VLT
®
HVAC Drive Instruction Manual
6-70 MG.11.A9.22 - VLT
®
is a registered Danfoss trademark
6
