Par. No. # Parameter description Default value
(SR = Size related)
4 set-up Change during oper-
ation
Conver-
sion index
Type
16-0* General Status 16-00 Control Word 0 N/A All set-ups FALSE 0 V2 16-01 Reference [Unit] 0.000 ReferenceFeedbackUnit All set-ups FALSE -3 Int32
16-02 Reference % 0.0 % All set-ups FALSE -1 Int16
16-03 Status Word 0 N/A All set-ups FALSE 0 V2
16-05 Main Actual Value [%] 0.00 % All set-ups FALSE -2 N2
16-09 Custom Readout 0.00 CustomReadoutUnit All set-ups FALSE -2 Int32 16-1* Motor Status 16-10 Power [kW] 0.00 kW All set-ups FALSE 1 Int32 16-11 Power [hp] 0.00 hp All set-ups FALSE -2 Int32 16-12 Motor voltage 0.0 V All set-ups FALSE -1 Uint16
16-13 Frequency 0.0 Hz All set-ups FALSE -1 Uint16
16-14 Motor Current 0.00 A All set-ups FALSE -2 Int32
16-15 Frequency [%] 0.00 % All set-ups FALSE -2 N2
16-16 Torque [Nm] 0.0 Nm All set-ups FALSE -1 Int32
16-17 Speed [RPM] 0 RPM All set-ups FALSE 67 Int32
16-18 Motor Thermal 0 % All set-ups FALSE 0 Uint8
16-22 Torque [%] 0 % All set-ups FALSE 0 Int16
16-26 Power Filtered [kW] 0.000 kW All set-ups FALSE 0 Int32
16-27
Power Filtered [hp] 0.000 hp All set-ups FALSE -3 Int32
16-3* Drive Status 16-30 DC Link Voltage 0 V All set-ups FALSE 0 Uint16 16-32 Brake Energy /s 0.000 kW All set-ups FALSE 0 Uint32
16-33 Brake Energy /2 min 0.000 kW All set-ups FALSE 0 Uint32
16-34 Heatsink Temp. 0 °C All set-ups FALSE 100 Uint8
16-35 Inverter Thermal 0 % All set-ups FALSE 0 Uint8
16-36 Inv. Nom. Current ExpressionLimit All set-ups FALSE -2 Uint32
16-37 Inv. Max. Current ExpressionLimit All set-ups FALSE -2 Uint32
16-38 SL Controller State 0 N/A All set-ups FALSE 0 Uint8
16-39 Control Card Temp. 0 °C All set-ups FALSE 100 Uint8
16-40 Logging Buffer Full [0] No All set-ups TRUE - Uint8 16-5* Ref. & Feedb. 16-50 External Reference 0.0 N/A All set-ups FALSE -1 Int16 16-52 Feedback [Unit] 0.000 ProcessCtrlUnit All set-ups FALSE -3 Int32 16-53 Digi Pot Reference 0.00 N/A All set-ups FALSE -2 Int16
16-54 Feedback 1 [Unit] 0.000 ProcessCtrlUnit All set-ups FALSE -3 Int32
16-55 Feedback 2 [Unit] 0.000 ProcessCtrlUnit All set-ups FALSE -3 Int32
16-56 Feedback 3 [Unit] 0.000 ProcessCtrlUnit All set-ups FALSE -3 Int32
16-58 PID Output [%] 0.0 % All set-ups TRUE -1 Int16
6.2.16 16-** Data Readouts
6 How to program the adjustable frequency
drive
VLT
®
HVAC Drive Instruction Manual
6-74 MG.11.A9.22 - VLT
®
is a registered Danfoss trademark
6
