Danfoss VLT User Manual

A2 A3 A5 B1 B2 B3 B4 C1 C2 C3 C4
IP20/21 IP20/21 IP55/66 IP21/55/66 IP21/55/66 IP20 IP20 IP21/55/66 IP21/55/66 IP20 IP20
Figure 3.1: Top and bottom mounting holes.
Figure 3.2: Top and bottom mounting holes. (B4+C3+C4 only)
Accessory bags containing necessary brackets, screws and connectors are included with the drives upon delivery.
All measurements in mm.
3.2.1 Mechanical Front Views
3 Mechanical installation VLT
®
HVAC Drive Instruction Manual
3-2 MG.11.A9.22 - VLT
®
is a registered Danfoss trademark
