[1117] XIF Revision Shows the version of the external interface file of the Neuron C chip on the LON option.
[1118] LonWorks Revision
[1501] Running Hours View the number of running hours of the motor.
[1502] kWh Counter View the line power consumption in kWh.
[1600] Control Word View the control word sent from the adjustable frequency drive via the serial communication port
in hex code.
[1601] Reference [Unit] Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in selected
unit.
[1602] * Reference % Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in percent.
[1603] Status Word Present status word
[1605] Main Actual Value [%] View the two-byte word sent with the status word to the bus master reporting the main actual value.
[1609] Custom Readout View the user-defined readouts as defined in par. 0-30
Custom Readout Unit
, par. 0-31
Custom
Readout Min Value
and par. 0-32
Custom Readout Max Value
.
[1610] Power [kW] Actual power consumed by the motor in kW.
[1611] Power [hp] Actual power consumed by the motor in HP.
[1612] Motor voltage Voltage supplied to the motor.
[1613] Frequency
[1614] Motor Current Phase current of the motor measured as effective value.
[1615] Frequency [%] Motor frequency, i.e., the output frequency from the adjustable frequency drive in percent.
[1616] Torque [Nm] Present motor load as a percentage of the rated motor torque.
[1617] Speed [RPM] Motor speed reference. Actual speed will depend on slip compensation being used (compensation
set in par. 1-62
Slip Compensation
). If not used, actual speed will be the value read in the display
minus motor slip.
[1618] Motor Thermal Thermal load on the motor, calculated by the ETR function. See also parameter group 1-9* Motor
Temperature.
[1622] Torque [%] Shows the actual torque produced, in percentage.
[1626]
[1627]
[1630] DC Link Voltage Intermediate circuit voltage in the adjustable frequency drive.
[1632] Brake Energy /s
[1633] Brake Energy /2 min
[1634] Heatsink Temp. Present heatsink temperature of the adjustable frequency drive. The cut-out limit is 203° ± 9°F [95°
± 5° C]; cutting back in occurs at 158° ± 9°F [70° ± 5°C].
[1635] Inverter Thermal
[1636] Inv. Nom. Current Nominal current of the adjustable frequency drive
[1637] Inv. Max. Current Maximum current of the adjustable frequency drive
[1638] SL Controller State
[1639] Control Card Temp. Temperature of the control card.
[1650] External Reference Sum of the external reference as a percentage, i.e., the sum of analog/pulse/bus.
6 How to program the adjustable frequency
drive
VLT
®
HVAC Drive Instruction Manual
6-14
MG.11.A9.22 - VLT
®
is a registered Danfoss trademark
6
