Danfoss VLTAutomationDrive FC 360 User Manual

4.4.1 Main Menu
Structure
0-** Operation / Display 0-0* Basic Settings 0-01 Language
0-03 Regional Settings 0-04 Operating State at Power-up
0-06 GridType [10] >380-440V/50Hz/IT-grid<
[11] >380-440V/50Hz/Delta< [12] >380-440V/50Hz<
[20] >440-480V/50Hz/IT-grid< [21] >440-480V/50Hz/Delta< [22] >440-480V/50Hz< [110] >380-440V/60Hz/IT-grid<
[111] >380-440V/60Hz/Delta< [112] >380-440V/60Hz< [120] >440-480V/60Hz/IT-grid<
[121] >440-480V/60Hz/Delta< [122] >440-480V/60Hz< 0-07 Auto DC Braking
0-1* Set-up Operations 0-10 Active Set-up *[1] >Set-up 1< [2] >Set-up 2< [9] >Multi Set-up< 0-11 Programming Set-up
0-12 Link Setups 0-16 Application Selection
*[0] None [1] >Process Close Loop<
[2] >Local/Remote< [3] >Speed Open Loop< [4] >Speed Close Loop<
[5] >Multi Speed<
0-3* LCP Custom Readout 0-30 Custom Readout Unit 0-31 Custom Readout Min Value 0-32 Custom Readout Max Value 0-4* LCP Keypad 0-40 [Hand on] Key on LCP 0-42 [Auto on] Key on LCP
0-44 [Off/Reset] Key on LCP
0-5* Copy/Save 0-50 LCP Copy *[0] >No copy< [1] >All to LCP< [2] >All from LCP< [3] >Size indep. from LCP<
0-51 Set-up Copy *[0] >No copy-
[1] >Copy from setup 1< [2] >Copy from setup 2<
[9] >Copy from Factory setup<
0-6* Password 0-60 Main Menu Password 1-** Load and Motor
1-0* General Settings 1-00 Configuration Mode [0]* >Open Loop<
[1] >Speed closed loop<
[3] >Process Closed Loop<
[4] >Torque open loop< [6] >Surface Winder< [7] >Extended PID Speed OL<
[9] >Central Winder< [10] >Positioning< [11] >Synchronisation< 1-01 Motor Control Principle
[0] >U/f< *[1] >VVC+< 1-03 Torque Characteristics *[0] >Constant torque<
[1] >Variable Torque< [2] >Auto Energy Optim. CT<
[3] >Auto Energy Optim. VT<
1-06 Clockwise Direction
1-1* Motor Selection 1-10 Motor Construction 1-2* Motor Data 1-20 Motor Power [2] >0.12 kW - 0.16 hp<
[3] >0.18 kW - 0.25 hp<
[4] >0.25 kW - 0.33 hp<
[5] >0.37 kW - 0.5 hp< [6] >0.55 kW - 0.75 hp<
*[7] >0.75 kW - 1 hp< [8] >1.1 kW - 1 hp<
[9] >1.5 kW - 2 hp<
[10] >2.2 kW - 3 hp<
[11] >3 kW - 4 hp< [12] >3.7 kW - 5 hp<
[13] >4 kW - 5.4 hp< [14] >5.5 kW - 7.5 hp<
[15] >7.5 kW - 10 hp<
[16] >11 kW - 15 hp<
[17] >15 kW - 20 hp< [18] >18.5 kW - 25 hp<
[19] >22 kW - 30 hp< [20] >30 kW - 40 hp<
[21] >37 kW - 50 hp<
[22] >45 kW - 60 hp< [23] >55 kW - 75 hp<
[24] >75 kW - 100 hp< [25] >90 kW - 120 hp<
[26] >110 kW - 150 hp<
1-22 Motor Voltage 1-23 Motor Frequency 1-24 Motor Current 1-25 Motor Nominal Speed 1-29 Automatic Motor Adaption (AMA)
*[0] >Off< [1] >Enable Complete AMA< [2] >Enable Reduced AMA<
1-3* Adv. Motor Data I
1-30 Stator Resistance (Rs)
1-33 Stator Leakage Reactance (X1)
1-35 Main Reactance (Xh)
1-39 Motor Poles
1-4* Adv. Motor Data II
1-42 Motor Cable Length
1-43 Motor Cable Length Feet
1-5* Load Indep. Setting 1-50 Motor Magnetisation at Zero Speed
1-52 Min Speed Normal Magnetising [Hz]
1-55 U/f Characteristic - U
1-56 U/f Characteristic - F
1-6* Load Depen. Setting 1-60 Low Speed Load Compensation
1-61 High Speed Load Compensation
1-62 Slip Compensation 1-63 Slip Compensation Time Constant 1-64 Resonance Dampening 1-65 Resonance Dampening Time Constant
1-7* Start Adjustments 1-71 Start Delay 1-72 Start Function [0] >DC Hold/delay time< *[2] >Coast/delay time<
[3] >Start speed cw<
[4] >Horizontal operation< [5] >VVC+ clockwise< 1-73 Flying Start *[0] >Disabled< [1] >Enabled< [2] >Enabled Always<
[3] >Enabled Ref. Dir.< [4] >Enab. Always Ref. Dir.< 1-75 Start Speed [Hz]
1-76 Start Current 1-78 Compressor Start Max Speed [Hz]
1-79 Compressor Start Max Time to Trip
1-8* Stop Adjustments 1-80 Function at Stop
*[0] >Coast< [1] >DC hold / Motor Preheat<
[3] >Pre-magnetizing< 1-82 Min Speed for Function at Stop [Hz]
1-9* Motor Temperature 1-90 Motor Thermal Protection *[0] >No protection< [1] >Thermistor warning< [2] >Thermistor trip<
[3] >ETR warning 1<
[4] >ETR trip 1< 1-93 Thermistor Source
2-** Brakes 2-0* DC-Brake 2-00 DC Hold/Motor Preheat Current
2-01 DC Brake Current 2-02 DC Braking Time
2-04 DC Brake Cut In Speed
2-1* Brake Energy Funct. 2-10 Brake Function
*[0] >Off<
[1] >Resistor brake< [2] >AC brake< 2-11 Brake Resistor (ohm)
2-12 Brake Power Limit (kW)
2-16 AC Brake, Max current 2-17 Over-voltage Control *[0] >Disabled<
[1] >Enabled (not at stop)<
[2] >Enabled< 2-19 Over-voltage Gain
2-2* Mechanical Brake 2-20 Release Brake Current 2-22 Activate Brake Speed [Hz] 3-** Reference / Ramps 3-0* Reference Limits 3-00 Reference Range *[0] >Min - Max< [1] >-Max - +Max< 3-01 Reference/Feedback Unit
3-02 Minimum Reference
3-03 Maximum Reference 3-04 Reference Function *[0] >Sum< [1] >External/Preset<
3-1* References 3-10 Preset Reference
>-100.00-100.00%< *0.00%
3-11 Jog Speed [Hz]
3-12 Catch up/slow Down Value 3-14 Preset Relative Reference 3-15 Reference 1 Source
[0] >No function< *[1] >Analog Input 53<
[2] >Analog Input 54< [7] >Frequency input 29<
[8] >Frequency input 33<
[11] >Local bus reference< [32] >Bus PCD< 3-16 Reference 2 Source
3-17 Reference 3 Source
3-18 Relative Scaling Reference Resource
3-4* Ramp 1 3-40 Ramp 1 Type *[0] >Linear< [2] >S-ramp Const Time< 3-41 Ramp 1 Ramp Up Time
>0.05-3600.00 s< * Size related
3-42 Ramp 1 Ramp Down Time
>0.05-3600.00 s< * Size related
3-5* Ramp 2 3-50 Ramp 2 Type 3-51 Ramp 2 Ramp Up Time 3-52 Ramp 2 Ramp Down Time 3-8* Other Ramps 3-80 Jog Ramp Time 3-81 Quick Stop Ramp Time 4-** Limits / Warnings 4-1* Motor Limits 4-10 Motor Speed Direction
[0] >Clockwise<
*[2] >Both directions< 4-12 Motor Speed Low Limit [Hz]
4-14 Motor Speed High Limit [Hz]
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
4-18 Current Limit 4-19 Max Output Frequency
4-2* Limit Factors 4-22 Break Away Boost 4-3* Motor Fb Monitor 4-30 Motor Feedback Loss Function 4-31 Motor Feedback Speed Error 4-32 Motor Feedback Loss Timeout 4-4* Adj. Warnings 2 4-40 Warning Freq. Low
4-41 Warning Freq. High
4-42 Adjustable Temperature Warning
4-5* Adj. Warnings 4-50 Warning Current Low 4-51 Warning Current High
4-54 Warning Reference Low 4-55 Warning Reference High
4-56 Warning Feedback Low 4-57 Warning Feedback High 4-58 Missing Motor Phase Function
4-6* Speed Bypass 4-61 Bypass Speed From [Hz]
4-63 Bypass Speed To [Hz]
5-** Digital In/Out 5-0* Digital I/O mode 5-00 Digital I/O Mode
*[0] >PNP< [1] >NPN< 5-01 Terminal 27 Mode
5-02 Terminal 29 Mode
5-1* Digital Inputs 5-10 Terminal 18 Digital Input [0] >No operation<
[1] >Reset< [2] >Coast inverse< [3] >Coast and reset inv< [4] >Quick stop inverse<
[5] >DC-brake inverse< [6] >Stop inverse< *[8] >Start< [9] >Latched start< [10] >Reversing< [11] >Start reversing<
[12] >Enable start forward< [13] >Enable start reverse<
[14] >Jog< [15] >Preset reference on<
[16] >Preset ref bit 0<
[17] >Preset ref bit 1<
[18] >Preset ref bit 2<
[19] >Freeze reference< [20] >Freeze output< [21] >Speed up<
