8.4 Connection Tightening Torques
When tightening all electrical connections it is very important to tighten with the correct torque. Too low or too high
torque results in a bad electrical connection. Use a torque wrench to ensure correct torque
Frame
size
Power [kW] Torque [Nm]
Mains Motor
DC
connection
Brake Earth Relay
J1 0.37-2.2 1.4 0,8 0,8 0,8 3 0,5
J2 3.0 -55 1.4 0,8 0,8 0,8 3 0,5
J3 7.5 1.4 0,8 0,8 0,8 3 0,5
J4 11-15 1,2 1,2 1,2 1,2 1,6 0,5
J5 18.5-22 1,2 1,2 1,2 1,2 1,6 0,5
J6 30-45 2 2 2 - 2 0.5
J7 55 12 12 12 - 2 0.5
J7 75 14 14 14 - 2 0.5
Table 8.8 Tightening of Terminals
Specifications
VLT
®
AutomationDrive FC 360 Quick Guide
44 MG06A102 - VLT
®
is a registered Danfoss trademark
88
