Danfoss VLTAutomationDrive FC 360 User Manual

Surroundings
Enclosure type J1-J7 IP20, IP21/Type 1
Vibration test all enclosure types 1.0 g
Relative humidity 5-95% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 60068-2-43) H
2
S test
class Kd
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature (at 60 AVM switching mode)
- with derating max. 55°C
1)
- with full output power of typical EFF2 motors (up to 90% output current) max. 50 °C
1)
- at full continuous FC output current max. 45 °C
1)
1)
For more information on derating see the VLT AutomationDrive FC 360 Design Guide, section on Special Conditions.
Minimum ambient temperature during full-scale operation 0°C
Minimum ambient temperature at reduced performance - 10°C
Temperature during storage/transport -25 to +65/70°C
Maximum altitude above sea level without derating 1000 m
Maximum altitude above sea level with derating 3000m
EMC standards, Emission EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EMC standards, Immunity
EN 61800-3, EN 61000-6-1/2,
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
Control Card Performance
Scan interval 1 ms
Protection and Features
•
Electronic thermal motor protection against overload.
•
Temperature monitoring of the heatsink ensures that the frequency converter trips if the temperature reaches 95°C
± 5°C. An overload temperature cannot be reset until the temperature of the heatsink is below 70°C ±5°C
(Guideline - these temperatures may vary for different power sizes, enclosures etc.). The frequency converter has
an auto derating function to avoid it's heatsink reaching 95 °C.
•
The frequency converter is protected against short-circuits on motor terminals U, V, W.
•
If a mains phase is missing, the frequency converter trips or issues a warning (depending on the load).
•
Monitoring of the intermediate circuit voltage ensures that the frequency converter trips if the intermediate circuit
voltage is too low or too high.
•
The frequency converter is protected against earth faults on motor terminals U, V, W.
Specifications
VLT
®
AutomationDrive FC 360 Quick Guide
MG06A102 - VLT
®
is a registered Danfoss trademark 41
8 8
