feeding cable from the CU 6105 Central Unit to the
units connected.
Please consult the next sections for details about the
number of units, which can be connected depending
on the cable length.
5.3 Max. number of units to be connected
The following tables shows the maximum number of
units, which can be connected to a CU 6105 Central
Unit.
In the tables the ‘Feeding Cable’ is defined as the
cable between the CU 6105 and the first Conference
Unit and the ‘Interconnecting Cable is defined as the
cable connecting two conference units.
5.3.1 Connection using only one
DCS-LAN chain
The following tables show the maximum number of
units, which can be connected to one DCS-LAN chain
output when only one DCS-LAN chain is in use.
5.3.1.1 DC 6120 P, DC 6190 P, DM 6680 P
Conference Units
Length of
Feeding Cable
Type CAT5e
AWG24
Length of inter
connecting
Cable, Type
CAT5e AWG24
Total cable
length
Max. number
of units pr
output
10 m 1 m 51 m 42
30 m 1 m 67 m 38
50 m 1 m 83 m 34
100 m
1 m
122 m
23
150 m 1 m 165 m 16
10 m 2 m 88 m 40
30 m 2 m 98 m 35
50 m
2 m
108 m
30
100 m 2 m 140 m 21
150 m 2 m 178 m 15
Figure 5.3-A DC 6120 P, DC 6190 P or DM 6680 P
Conference Units connected
5.3.1.2 DC 6990 P Conference Unit
Length of
Feeding Cable
Type CAT5e
AWG24
Length of inter
connecting
Cable, Type
CAT5e AWG24
Total cable
length
Max. number
of DC 6990 P
per output
10 m
1 m
35 m
22
30 m 1 m 53 m 22
50 m 1 m 70 m 21
100 m 1 m 112 m 13
150 m
1 m
158 m
9
10 m 2 m 56 m 25
30 m 2 m 72 m 22
50 m 2 m 90 m 19
100 m
2 m
124 m
13
150 m 2 m 166 m 9
Figure 5.3-B DC 6990 P Conference Units connected
5.3.1.3 CM/DM 6080 F / DM 6620 F
Chairman/Delegate
Length of
Feeding Cable
Type CAT5e
AWG24
Length of inter
connecting
Cable, Type
CAT5e AWG24
Total cable
length
Max. number
of DC 61xxP
per output
10 m 1 m 39 m 30
30 m
1 m
56 m
27
50 m 1 m 73 m 24
100 m 1 m 115 m 16
150 m 1 m 160 m 11
10 m
2 m
64 m
28
30 m 2 m 78 m 25
50 m 2 m 94 m 23
100 m 2 m 130 m 16
150 m
2 m
170 m
11
Figure 5.3-C CM/DM 6080 F or DM 6620 F
Chairman/Delegate Units connected
