6.3.6 Connecting interpretation units
The CU 6105 is connected to the Conference Units
using EC 6001-xx Cat5e cables.
Both the DCS-LAN chain connectors on the CU 6105
can be used for connecting the Conference Units.
In this example one or more Interpreter Booth with
Interpreter Units and DH 6021 Headphone is
connected to the units.
Audio from the Interpreter Units can then be heard in
the headphones connected to the Chairman and
Delegate Units.
Figure 6.3-G DCS 6000 Digital Conference System with interpretation functionality.
