Dantherm DanX 1 - APPENDIX; 9.1 Modbus Register XD

9. APPENDIX
45
9.1 Modbus register XD
Register
Register Name
Type
Message Type
Scaling Factor
Mapped Datapoint
40100
Room_Temp
uint16
Read only
0,1 to be applied by Modbus Master
MB_Room_Temp
40101
Supply_Temp
uint16
Read only
0,1 to be applied by Modbus Master
MB_Supply_Temp
40102
Outdoor_Temp
uint16
Read only
0,1 to be applied by Modbus Master
MB_Outdoor_Temp
40103
Room_Humidity
uint16
Read only
MB_Room_Humidity
40104
Return_AirVolume
uint16
Read only
Return_Airvolume
40105
Supply_AirVolume
uint16
Read only
Supply_Airvolume
40106
Duct_Dampers
uint16
Read only
MB_Duct_Dampers
40107
ByPass_Damper
uint16
Read only
MB_ByPass_Damper
40108
Heating_Signal
uint16
Read only
MB_Heating_Signal
40109
Unit_Status
uint16
Read only
UNIT_STATUS_OPEN
40110
Program_Status
uint16
Read only
Program_Status
40111
Open_Temp
uint16
Read and Write
0,1 to be applied by Modbus Master
MB_Open_Temp
40112
Closed_Temp
uint16
Read and Write
0,1 to be applied by Modbus Master
MB_Closed_Temp
40113
Open_Humidity
uint16
Read and Write
MB_Open_humidity
40114
Closed_Humidity
uint16
Read and Write
MB_Closed_humidity
40115
Min_Fresh_Air
uint16
Read and Write
MB_Min_Fresh_Air
40116
Return_Fan_High
uint16
Read and Write
MB_Return_Fan_High
40117
Return_Fan_Low
uint16
Read and Write
MB_Return_Fan_low
40118
Supply_Fan_High
uint16
Read and Write
MB_Supply_Fan_High
40119
Supply_Fan_Low
uint16
Read and Write
MB_Supply_Fan_Low
40120
Max_Supply_Temp
uint16
Read and Write
0,1 to be applied by Modbus Master
MB_Max_Sup
40121
Min_Supply_Temp
uint16
Read and Write
0,1 to be applied by Modbus Master
MB_Min_Sup
40150
Common_Fault
bool
Read only
(0) Normal / (1) Alarm
MB_Common_Fault
40151
Fan_Alarm
bool
Read only
(0) Normal / (1) Alarm
MB_Fan_Alarm
40152
CheckFilters
bool
Read only
(0) Normal / (1) Alarm
CheckFilters
40153
Fire_Alarm
bool
Read only
(0) Normal / (1) Alarm
MB_Fire_Alarm
40154
HeatingCoil_Alarm
bool
Read only
(0) Normal / (1) Alarm
MB_HeatCoilAlarm
40155
Heating_Coil_Pump
bool
Read only
(0) Off / (1) On
MB_HeatCoilPump
40156
DX_Cooling
bool
Read only
(0) Off / (1) On
MB_DX_Cooling
40157
External_Stop
bool
Read and Write
(0) Auto / (1) Stop
External_Stop
40158
Time_Program
bool
Read and Write
(0) MVC80 / (1) BMS
Time_Program
