Data Translation DT300 Series Getting Started Manual

Chapter 4
30
Using an STP68 or STP68-DIN Screw
Terminal Panel
To attach the STP68 or STP68-DIN screw terminal panel to the DT300
Series board, you need the EP305 or equivalent cable. The STP68,
STP68-DIN, and the EP305 are offered by Data Translation as
accessories to the DT300 Series boards.
Connector J1 on the STP68 and STP68-DIN attaches to connector J1
on the DT300 Series board.
Figure 5 illustrates how to attach the STP68 or STP68-DIN screw
terminal panel to a DT300 Series board.
Figure 5: Attaching the STP68 or STP68-DIN Screw Terminal Panel to a
DT330 Series Board
The STP68 and STP68-DIN screw terminal panels do not require
configuration.
DT330 Series
Board
J1
EP305 Cable
J1
STP68 or STP68-DIN
Screw Terminal Panel
