Wiring Signals
39
5
5
5
5
5
5
5
5
5
Analog Input Screw Terminals
Table 2 lists the screw terminal (TB) assignments for analog input
connections on the STP300 screw terminal panel. The corresponding
resistors and their use are also listed.
Table 2: Analog Input Screw Terminal Assignments on the STP300
TB # J1 Pin # Description
Resistor Use
Bias Return
Resistor
Current Shunt
Resistor
1 68 Analog Input 0
−
R9
2 67 Analog Input 8/
Analog Input 0 Return
R1
3 34 Analog Input 1
−
R10
4 33 Analog Input 9/
Analog Input 1 Return
R2
5 66 Analog Input 2
−
R11
6 65 Analog Input 10/
Analog Input 2 Return
R3
7 32 Analog Input 3
−
R12
8 31 Analog Input 11/
Analog Input 3 Return
R4
9 64 Analog Input 4
−
R13
10 63 Analog Input 12/
Analog Input 4 Return
R5
11 30 Analog Input 5
−
R14
12 29 Analog Input 13/
Analog Input 5 Return
R6
