DataCard CD800 Quick Install

12 CLM Laminator
CLM Laminator Quick Install and Upgrade Guide
e. Press down on the printer carefully, but rmly, to
position it.
f. Push the printer locking lever to the right to lock the
printer to the laminator. Make sure that the printer is
locked securely to the laminator.
g. Connect the interconnect cable to the interconnect data
port of the printer.
Laminator
Back
Laminator
Front
d. Lift the printer over the laminator and align the pins on
the laminator with the holes on the underside of the
printer.

DataCard CD800 Specifications

General

Print Resolution	300 dpi
Weight	12 lbs (5.4 kg)
Power Requirements	100-240 VAC, 50/60 Hz
Print Technology	Dye-sublimation
Card Capacity	100 cards (standard hopper)
Connectivity	USB
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Compatibility	Windows
Card Thickness	0.020" - 0.040" (0.51 mm - 1.02 mm)
