DATAEAGLE 4000 Series - Leds

3 Description
3.3.2 LEDs
ON LED
LED Indication State Description
ON Green Permanently lit Power ok
Off Off Power not ok
RX LED
LED Indication State Description
RX Yellow Flashing Radio reception
Off Off No radio reception
LINK LED
LED Indication State Description
LINK Blue On/Blinking Radio connection(s)
active
Off Off Radio Connection(s)
inactive
STAT LED
LED Anzeige Zustand Beschreibung
STAT Red On (Master) no Ethernet connection
Red Blinking
(Master)
Ethernet error detected
Off Off no Error detected
For more information, check the device diagnostics.
